Transparent Outdoor LED Screen OLED Outdoor Small Pitch Transparent Display Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P3.47-6.94,P6.94 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | 3-6 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000sqm per month |
|
Detail Information |
|||
| Pixel Pitch: | P3.47-6.94,P6.94 | IP Level: | IP65 |
|---|---|---|---|
| Brightness: | 5000nits | Transparent Rate: | 50% |
| Power Consumption: | Max800W/sqm, Avg240W/sqm | Weight: | 16kg/sqm |
| Pixel Configuration: | RGB | Scan Mode: | 1/4 |
| Led Type: | SMD1415 1R1PG1PB UV | Product: | Outdoor Transparent LED Display |
| Origin: | China | Control System: | Synchronization/ Asynchronization |
| Highlight: | OLED outdoor transparent display screen,Small Pitch outdoor transparent display screen,Transparent Outdoor LED Screen |
||
Product Description
LED outdoor small pitch transparent display screen, LED transparent dance rental main screen, 3D outdoor transparent display screen
Outdoor transparent LED Display / Carbon fiber Rental LED Screen / High transparency / Waterproof and Anti-wind
FEATURES
- SMALL PITCH
Industry minimum spacing outdoor transparent display, high brightness, and high refresh.
- HIGH TRANSPARENCY
Unparalleled transparency, the transparent rate could be from 35% to 70%.
- CURVED
Curved, 90 degree
- EASY INSTALLATION AND MAINTENANCE
convenient installation, fast maintenance, Can repair lamp beads and chips in front to reduce scrap!
TECHNICAL SPECIFICATIONS
| Product Model: | P3.47-6.94 |
| Pixel Pitch: | 3.47-6.94mm |
| LED Type: | SMD1415 |
| Cabinet Dimension: | 1000×500 mm |
| Module Size: | 500x125mm |
| Cabinet Weight: | 8 kg/cabinet |
| Cabinet Material: | Aluminum |
| Driving Type: | 1/10 |
| Brightness: | 4500-5000 nits |
| Max/Avg Power: | 800/240 W/sqm |
| Maintenance: | Front & Rear service |
| Environment: | Outdoor Use |
| IP Rating: | F: IP65, R: IP65 |
| Refresh Rate: | >3840 Hz |
| Installation Type: | Mounting/Hanging/Stacking |
| Gray Scale: | 14 bit |
| Viewing Angle: | H:140°；V:120° |
| Operational Temp: | -40℃~+60℃ |
| Operational Humidity: | 10%~90% RH |
INSTALLATION
Curved Installation
90 degress Installation
APPLICATION
FAQ:
1. Q: Are you a manufacturer or trading company?
A: We are LED manufacturer, OEM & ODM optional, multi-solutions provider, more than 10 years experience in LED industry! What’s more, Visual World is a modern factory dedicated to applying artificial intelligence to the LED industry.
2. Q: How about the warranty?
A: We provide at least 2 years warranty, and some products can be 5 years warranty. Even after the warranty, we can still repair product for free, you just need to pay for the shipping cost.
3. Q: Can you customize my logo on LED display?
A: Of course, we can print your logo on PCB and LED Cabinet if you need. Thus you will keep your own brand.
