Outdoor P5.2-10.4 Transparent LED Screen 15kg 1000×500mm IP65 5000 nits
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS |
| Model Number: | P5.2-10.4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood box |
| Delivery Time: | 10 work days |
| Payment Terms: | T/T |
| Supply Ability: | 2200 sqm/month |
|
Detail Information |
|||
| Product Name: | Outdoor P5.2-10.4 Transparent LED Screen 15kg 1000×500mm IP65 5000 Nits | LED Type: | SMD1921 |
|---|---|---|---|
| Operating Temperature: | -20℃~+50℃ | Lifespan: | 100,000 Hours |
| Module Size: | 500x125 MM | Viewing Angle: | H:140°；V:140° |
| Gray Scale: | 14bit | Pixel Pitch: | 5.2-10.4mm |
| Highlight: | Outdoor P5.2 transparent LED screen,IP65 waterproof transparent LED display,5000 nits high brightness LED screen |
||
Product Description
Outdoor P5.2-10.4 Transparent LED Screen 15kg 1000×500mm IP65 5000 nits
Product Specifications
| Product Name | Outdoor P5.2-10.4 Transparent LED Screen 15kg 1000×500mm IP65 5000 nits |
| LED Type | SMD1921 |
| Operating Temperature | -20℃~+50℃ |
| Lifespan | 100,000 Hours |
| Module Size | 500x125 MM |
| Viewing Angle | H:140°；V:140° |
| Gray Scale | 14bit |
| Pixel Pitch | 5.2-10.4mm |
Product Overview
Transparent LED screens provide an effective and compelling alternative to large format LED screens. The images are created by programming the LEDs to work together, displaying pixel colors that combine to form complete images. When integrated into glass curtain walls, this creates particularly powerful visual effects, making them ideal for retail buildings and glass structures without compromising architectural design.
Key Features
- High contrast and brightness: Extra flexibility with weight under 8.5 Kg/m² and thickness less than 25mm, making transportation and assembly cost-effective
- Stability and long lifespan: Low power consumption and energy efficient design extends LED lifetime
- High transparency and brightness: 20-80% transparency rate for glass wall mounting with >6500 nits brightness suitable for all outdoor environments
Technical Parameters
| Parameter | Specification |
|---|---|
| Pixel Pitch | 5.2-10.4 mm |
| LED Type | SMD1921 |
| Cabinet Dimension | 1000×500mm |
| Module Size | 500x125 mm |
| Cabinet Weight | 15 kg |
| Cabinet Material | Aluminum |
| Driving Type | 1/6 |
| Brightness | 5000 nits |
| Max/Avg Power | 800/280 W/m² |
| Maintenance | Front service |
| IP Rating | IP65 |
| Refresh Rate | >1920 Hz |
| Transparent Rate | 60% |
| Gray Scale | 14 bit |
| Viewing Angle | H:140°；V:140° |
| Operational Temp | -20℃~+50℃ |
| Operational Humidity | 10%~90% RH |
Applications
Ideal for shopping malls, entertainment venues, building construction, government agencies, trade fairs, exhibitions, press conferences, airports, hotels, station waiting areas, indoor stadiums, and various public facilities.
Frequently Asked Questions
Q1: Are you a manufacturer or trade company?
A1: We are a professional OEM/ODM manufacturer with more than 10 years of experience in the LED display screen industry.
Q2: What can I get from you?
A2: LED modules, LED display screens, and complete LED display screen series products.
Q3: How about your warranty period?
A3: 1-3 years warranty covering structure design, installation issues, and programming screens.
Q4: How to use LED screens?
A4: We provide complete technical support with dedicated engineers and sales managers assigned to each customer, offering 24/7 service from pre-sales to after-sales.
Q5: What other services can you provide for LED displays?
A5: As our customer, you'll receive dedicated technical support including 1-3 annual on-site visits for maintenance and technology updates.
