P5.2-10.4 Outdoor Transparent LED Display 1000×500mm 75% High Transparency
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS |
| Model Number: | P5.2-10.4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood box |
| Delivery Time: | 10 work days |
| Payment Terms: | T/T |
| Supply Ability: | 2200 sqm/month |
|
Detail Information |
|||
| Product Name: | P5.2-10.4 Outdoor Transparent LED Display 1000×500mm 75% High Transparency | Pixel Pitch: | 5.2-10.4mm |
|---|---|---|---|
| LED Type: | SMD1921 | Cabinet Dimension: | 1000×500mm |
| Module Size: | 500x125mm | Brightness: | 5000nits |
| Transparency Rate: | 75% | Refresh Rate: | 1920Hz |
| Highlight: | P5.2 Outdoor Transparent LED Display,1000×500mm Outdoor Transparent LED Display |
||
Product Description
P5.2-10.4 Outdoor Transparent LED Display 1000×500mm 75% High Transparency
Product Description:
P5.2-10.4 Transparent LED screens provide a highly effective and captivating alternative to traditional large-format LED displays. These screens produce cohesive images by coordinating LEDs to light up in precise pixel colors. When integrated into glass curtain walls, they create an imposing effect, allowing designers to implement display solutions for retail spaces—particularly those with glass facades—without interrupting the architectural design.
Features:
- High contrast and brightness
Extra flexibility, weighs under 8.5 Kg/m2 and thinner than 25mm. Very convenient to use and move, saving a lot of transportation and assembling costs
- Stability long life time
Low power comsumption and energy saving, Low consumption of electricity to increase the lifetime of LED
- High Transparency
75% transparency rate, see through, suitable for glass wall mounting；>5000 nits brightness, for all outdoor environment
Technical Parameters:
| Technical Parameters | Transparent LED Display |
| Pixel Pitch: |
5.2-10.4 mm
|
| LED Type: | SMD1921 |
| Cabinet Dimension: | 1000×500mm |
| Module Size: | 500x125 mm |
| Cabinet Weight: | 15 kg |
| Cabinet Material: | Aluminum |
| Driving Type: | 1/6 |
| Brightness: | 5000 nits |
| Max/Avg Power: | 800/280 W/m² |
| Maintenance: | Front service |
| IP Rating: | IP65 |
| Refresh Rate: | >1920 Hz |
| Transparent Rate: | 75% |
| Gray Scale: | 14 bit |
| Viewing Angle: | H:140°；V:140° |
| Operational Temp: | -20℃~+50℃ |
| Operational Humidity: | 10%~90% RH |
| Installation Type: | Mounting/Hanging |
Applications:
Widely utilized in shopping malls, entertainment venues, architectural projects, government institutions, trade shows, and for purposes such as exhibitions, press conferences, airports, hotels, station waiting areas, indoor arenas, and various other public facilities.
FAQ:
Q1:Are you the manufacturer or trading company? And where is your factory?
Our company is located in Shenzhen China, which enjoys the transportation and good reputation among our domestic and overseas customers for more than 10 years.
Q2: What kind of package can you choose?
A2: Wooden case or airflight case.
Q3: What is LED?
A3: LED is the abbreviation leds (LIGHT EMITTING DIODE), it"s emit visible wave lengths led in the LED display industry
Q4: What is a pixel and pixel pitch?
A4: The pixel is the smallest unit of light emitting,consists of red,green and blue colors.The same as ordinary computer monitors.
Pixel pitch refers to the center of the distance between two adjacent pixels.
Q5: What is the LED display module?
A5: The base unit determined by circuit and installation structure,has the display function,can simple assembling.
Q6: What is 3 in 1? What is its advantages and disadvantages?
A6: The RGB color of LED chips encapsulation SMT light vertical tied together according to certain spacing.
The advantages are: simple production, display effect is good.
The disadvantage is spectral color separation difficult, high cost.
