P5.2-10.4 Outdoor Transparent LED Display Front Service 5000 nits For Trade Shows
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS |
| Model Number: | P5.2-10.4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood box |
| Delivery Time: | 10 work days |
| Payment Terms: | T/T |
| Supply Ability: | 2200 sqm/month |
|
Detail Information |
|||
| Product Name: | P5.2-10.4 Outdoor Transparent LED Display Front Service 5000 Nits For Trade Shows | Pixel Pitch: | 5.2-10.4mm |
|---|---|---|---|
| LED Type: | SMD1921 | Cabinet Dimension: | 1000×500mm |
| Module Size: | 500x125mm | Brightness: | 5000nits |
| Transparency Rate: | 75% | Refresh Rate: | 1920Hz |
Product Description
P5.2-10.4 Outdoor Transparent LED Display Front Service 5000 nits For Trade Shows
Product Description:
P5.2-10.4 Transparent LED screens provide a highly effective and captivating alternative to traditional large-format LED displays. These screens produce cohesive images by coordinating LEDs to light up in precise pixel colors. When integrated into glass curtain walls, they create an imposing effect, allowing designers to implement display solutions for retail spaces—particularly those with glass facades—without interrupting the architectural design.
Features:
- High contrast and brightness
Extra flexibility, weighs under 8.5 Kg/m2 and thinner than 25mm. Very convenient to use and move, saving a lot of transportation and assembling costs
- Stability long life time
Low power comsumption and energy saving, Low consumption of electricity to increase the lifetime of LED
- High Transparency
75% transparency rate, see through, suitable for glass wall mounting；>5000 nits brightness, for all outdoor environment
Technical Parameters:
| Technical Parameters | Transparent LED Display |
| Pixel Pitch: |
5.2-10.4 mm
|
| LED Type: | SMD1921 |
| Cabinet Dimension: | 1000×500mm |
| Module Size: | 500x125 mm |
| Cabinet Weight: | 15 kg |
| Cabinet Material: | Aluminum |
| Driving Type: | 1/6 |
| Brightness: | 5000 nits |
| Max/Avg Power: | 800/280 W/m² |
| Maintenance: | Front service |
| IP Rating: | IP65 |
| Refresh Rate: | >1920 Hz |
| Transparent Rate: | 75% |
| Gray Scale: | 14 bit |
| Viewing Angle: | H:140°；V:140° |
| Operational Temp: | -20℃~+50℃ |
| Operational Humidity: | 10%~90% RH |
| Installation Type: | Mounting/Hanging |
Applications:
Widely utilized in shopping malls, entertainment venues, architectural projects, government institutions, trade shows, and for purposes such as exhibitions, press conferences, airports, hotels, station waiting areas, indoor arenas, and various other public facilities.
FAQ:
Q1:Are you a manufacturer or trading company?
Q2: How do we ensure quality?
A2: Seven quality control steps ensure that the screens you order are of good quality
1). We are committed to using premium-grade LED components.
2). We have a complete quality inspection system, and professional technical workers and machines are used to inspect materials.
3). Each product is strictly tested at least 4 times before shipment.
4). All modules are subjected to a 48-hour high-temperature aging test before assembling the cabinet.
5). After the cabinet is assembled, all functions of each cabinet are tested.
6). All tested cabinets are assembled and debugged and then subjected to a 72-hour aging test.
7). All products and spare parts are checked and confirmed again during packaging.
Q3:What is your MOQ?
A3:Any quantity is acceptable for your order. And the price is negotiable for large quantity.
Q4: What is your best service?
A4: 1: One to one sales engineer to customer responsibility system;
2. Know your project and provide the best solution for it;
3. Track your order and let you know each step and detail of it;
4. Teach you how to install and use the screen;
5. Care the subsequent use of your screen and ensure your after - sales service be well.
Q5: How long does it take to ship?
A5: Express and air freight usually take 5-10 days. Sea freight takes about 15-55 days according to different countries.
