P5.2-10.4 Outdoor Transparent LED Display 5000nits 75% Transparency 1000×500mm
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS |
| Model Number: | P5.2-10.4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood box |
| Delivery Time: | 10 work days |
| Payment Terms: | T/T |
| Supply Ability: | 2200 sqm/month |
|
Detail Information |
|||
| Product Name: | P5.2-10.4 Outdoor Transparent LED Display 5000nits 75% Transparency 1000×500mm | Pixel Pitch: | 5.2-10.4mm |
|---|---|---|---|
| LED Type: | SMD1921 | Cabinet Dimension: | 1000×500mm |
| Module Size: | 500x125mm | Brightness: | 5000nits |
| Transparency Rate: | 75% | Refresh Rate: | 1920Hz |
| Highlight: | 75% Transparency Outdoor Transparent LED Display,1000×500mm Outdoor Transparent LED Display,5000nits Outdoor Transparent LED Display |
||
Product Description
P5.2-10.4 Outdoor Transparent LED Display 5000nits 75% Transparency 1000×500mm
Product Description:
The P5.2-10.4 high-transmittance LED transparent display is a new generation of LED display technology. It maintains an attractive installation appearance while delivering rich colors and fine details in dynamic images. This outdoor transparent display features small light spots, soft brightness, high density, excellent display performance, and seamless splicing, providing a perfect visual experience.
Features:
- Low power consumption
Saving energy by more than 30% compared with the normal screen, energy-saving and environment-friendly.
- Easy installation
No need to change any Building Structure for installation.Just hanging and Mounting.
- High Transparency
Based on the Horizontal arrangement and lighting technology, it is up to 75% transparency.
Technical Parameters:
| Technical Parameters | Transparent LED Display |
| Pixel Pitch: |
5.2-10.4 mm
|
| LED Type: | SMD1921 |
| Cabinet Dimension: | 1000×500mm |
| Module Size: | 500x125 mm |
| Cabinet Weight: | 15 kg |
| Cabinet Material: | Aluminum |
| Driving Type: | 1/6 |
| Brightness: | 5000 nits |
| Max/Avg Power: | 800/280 W/m² |
| Maintenance: | Front service |
| IP Rating: | IP65 |
| Refresh Rate: | >1920 Hz |
| Transparent Rate: | 75% |
| Gray Scale: | 14 bit |
| Viewing Angle: | H:140°；V:140° |
| Operational Temp: | -20℃~+50℃ |
| Operational Humidity: | 10%~90% RH |
| Installation Type: | Mounting/Hanging |
Applications:
- Store glass showcase
LED transparent screens have brought revolutionary changes to retailers and are increasingly popular in fields such as building facades, glass window decorations, and interior decorations.
- Shopping mall supermarket
There is a wide range of application scenarios in shopping malls such as sightseeing elevators, atriums, and glass partitions. LED transparent screens effectively combine modern artistic beauty with the shopping mall environment.
- Glass curtain wall
Many buildings in the city use glass curtain walls, which are eye-catching and can be used as outdoor advertising carriers.
Support and service:
Pre-sale service:
- Inquiries answered within 24 hours.
- Market research and forecasts.
- Customized solutions based on customer needs.
- Data sheets and samples provided.
- Additional services like custom packing and factory visits.
In-sale service:
- Continuous monitoring of production.
- Photos and videos of production upon request.
- Free spare parts.
After-sale service:
- Complaints addressed within 24 hours.
- Maintenance guidance and solutions within 48 hours.
- 24-month warranty.
- Free technician training.
- Free documents: installation guide, software manual, maintenance guide, and control system software CD.
FAQ:
Q1: What kind of led display we provide?
A1: We have indoor/outdoor/rental/Advertising/transparent and poster LED display for your choice.
Q2: Do your led display comply with international certification standards?
A2: Yes, our led display comply with various international certification standards, such as CE certification, RoHS
certification, FCC certification, and so on.
Q3: Do you support custom design and customization requests for your led display?
A3: Yes, we can provide custom design and customization production according to customers' needs to meet their special
requirements and demands.
Q4: How Can We Guarantee Quality?
A4: Seven quality control steps ensure your ordered screens good:
1).Our customers are long-term cooperated large famous company.
2).Material check by professional workers and machines.
3).Debug every modules.
4). 48-hour aging test for all modules before assembling.
5).Test every cabinet's function after assembling by engineers and machines.
6).72-hour aging test for whole screen before shipment.
7). All details final inspection again before package.
Q5: How about the warranty?
A5: 2 years warranty.
