P2.85 Outdoor LED Display Module 320x320mm Die-casting AL IP67 Full Front Access
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, EMC, LVD, ROHS, FCC |
| Model Number: | P2.85 |
| Document: | SMART BLOCK series（waterm....pdf |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | plywood case, carton box |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T |
| Supply Ability: | 2000sqm/month |
|
Detail Information |
|||
| Product Name: | P2.85 Outdoor LED Display Module 320x320mm Die-casting AL IP67 Full Front Access | Pixel Pitch: | 2.85mm |
|---|---|---|---|
| LED Type: | SMD1415 | Maintenance: | Full Front Access |
| Brightness: | 5000 Nits | Refresh Rate: | 3840Hz |
| Module Material: | Die-casting Aluminum | Control System: | NovaStar |
| Highlight: | P2.85 outdoor LED display module,320x320mm die-casting AL LED module,IP67 full front access LED display |
||
Product Description
P2.85 Outdoor LED Display Module 320x320mm Die-casting AL IP67 Full Front Access
The P2.85 Outdoor LED Display Module delivers exceptional visual performance for various outdoor applications. With a 2.85mm pixel pitch, this module ensures high clarity and detailed image display, effectively capturing viewer attention from distance.
Constructed with die-casting aluminum cabinet, this module combines lightweight design with superior durability. The cabinet facilitates easy installation and integration into diverse structures including building facades and freestanding frames.
Key Features
- Die-casting Aluminum: Lightweight and durable aluminum panel ensures precise assembly with accurate hole positioning
- Front Access Maintenance: Magnetic LED modules securely connect to frame with optional safety rope for enhanced connection
- Integrated Power Box: Power supply, receiving card and hub board simplified into compact power box for individual module operation
- Curved Video Wall Capability: 45° edge modules compatible with custom metal cabinets using magnets for curved LED wall construction
- 2-in-1 Transmission Cable: Customized cable enables simultaneous current and signal transmission for streamlined connectivity
Technical Specifications
| Product Model: | SMART BLOCK |
| Pixel Pitch: | 2.85 mm |
| LED Type: | SMD1415 |
| Pixel Density: | 122,500 dots/sqm |
| Cabinet Dimension: | 320x320mm |
| Module Resolution: | 112×112 |
| Module Weight: | 1.54 kg |
| Module+Frame Weight: | 2.22 kg |
| Module Material: | Die-casting aluminum |
| Brightness: | 5000 nits |
| Max/Avg Power: | 800/280 W/m² |
| Maintenance: | Front service |
| IP Rating: | IP67 |
| Refresh Rate: | >3840 Hz |
| Viewing Angle: | H:140°; V:160° |
| Operational Temperature: | -30℃ to +60℃ |
Applications
Ideal for advertising displays, informational signage, and event backgrounds. The high brightness and resolution effectively attract attention and deliver messages clearly in outdoor environments.
Frequently Asked Questions
Q: What is the minimum order quantity for your products?
A: We have no minimum order limit for different screen sizes. Typically, screens with more than 50,000 dots provide clear video visibility for viewers.
Q: What input formats does the sending unit support?
A: Supports DVI, HDMI, VGA, DP and multiple input signals. Compatible with 1024×768, 1280×1024, 1080P, 2K, 4K and 8K resolutions.
Q: How do panels connect to each other?
A: Each panel features one EtherCon input and one EtherCon output, making inter-panel connections simple and efficient.
Q: What are your payment terms?
A: 30% deposit by wire transfer, with 70% balance payment due before shipment.
Q: How do your displays mount?
A: Our design team can create custom frames and mounting solutions specific to your installation requirements. We offer various mounting options including trussing and permanent installation solutions.
