P3.91 Zirca Series Outdoor Fixed LED Display Only 87mm Thick 19.5kg 500x1000mm
P3.91 Zirca Series Outdoor Fixed LED Display Only 87mm Thick 19.5kg 500x1000mm
Brand Name
VW
Product Model
P3.91
Certificate
CE, ROHS, EMC
Country Of Origin
CN
MOQ
Negotiate
Unit Price
Negotiate
Payment Method
T/T,L/C
Supply Capacity
2000sqm/month
Product Details
Highlight:
P3.91 outdoor LED display
,87mm thin LED screen
,500x1000mm fixed LED panel
Product Name:
P3.91 Zirca Series Outdoor Fixed LED Display Only 87mm Thick 19.5kg 500x1000mm
Pixel Pitch:
3.91mm
Cabinet Size:
500*1000*87mm
Module Size:
500*250*14mm
Cabinet Weight:
19.5kg/Cabinet
Brightness:
7500CD/m²
IP Rating:
IP65
Maintenance:
Front/Back
Product Description
Detailed Specifications And Features
P3.91 Zirca Series Outdoor Fixed LED Display Only 87mm Thick 19.5kg 500x1000mm
Product Description:
High-precision aluminum profile cabinet is only 87mm thick/19.5kg (500×1000mm),500×1000mm and 500×750mm cabinets are free to mix and match shaped shapes, sharing the same type of control box. Push-button lock realizes 5 seconds fast disassembly and assembly, optional arc lock supports curved surface splicing.
Features:
- Point By Point Calibration: Fine-tune the white balance of each lamp bead point by point to eliminate chromatic aberration and light spots, achieve pixel-level display consistency.
- Work In Silence: Fanless silent design, working noise ≤ 40dB (A) ambient sound level.
- Cabinets Design: The 500x1000mm and 500x750mm cabinets can be mixed and assembled into a variety of shapes; sharing a simple mini control box saves installation and calibration time.
Technical Parameters:
| Item | Specification Parameter |
| PixelPitch | 3.91mm |
| Resolution rate | 128*64mm |
| Module Size | 500*250*14mm |
| Pixel LED | SMD1921 Black led |
| Module Power | ≤74W |
| Driving IC | ICN2055 |
| Drivingway | 1/8 |
| Material | Aluminum profile |
| Cabinet Weight (kg/Cabinet) |
19.5kg |
| Resolution rate | 128*256Dots |
| Cabinet Size | 500*1000*87mm |
| Module quantity | 1*4 |
| Density | 65536 Dots/㎡ |
| Brightness | 7500CD/m² |
| View Angel | H/V:120°/120° |
| Maximal power/㎡ | ≤650W/㎡ |
| Average Power/㎡ | ≤220W/㎡ |
| Refresh Frequency | 3840Hz |
| Gray Grade | ≥13bit |
| Protection grade | IP65 |
| Maintenance | Front/Back |
Application:
- Outdoor creative modeling
- Building entrance
- Park entrance
- Swimming pool
FAQ
Q1: What is the control system? How is it?
A1: We use Nova Taurus Series asynchronous control system. Support cluster play and management. Support APP/Phone/ WIFI/ Ipad/ Laptop/ PC/ Cloud control. It’s very easy and convenient to control.
Q2: Can I have a sample order for led screen?
A2: Yes, we welcome sample order to test and check quality. Mixed samples areacceptable.
Q3:Is it OK to print my logo on product?
Q3:Is it OK to print my logo on product?
A3: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q4: What is your best service?
Q4: What is your best service?
A4: 1: One to one sales engineer to customer responsibility system;
2. Know your project and provide the best solution for it;
3. Track your order and let you know each step and detail of it;
4. Teach you how to install and use the screen;
5. Care the subsequent use of your screen and ensure your after - sales service be well.
Q5. How about your delivery time?
Q5. How about your delivery time?
A5: Generally, it will take 7-15 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
Q6:How about your Warranty Term?
Q6:How about your Warranty Term?
A6: 2-year warranty. Structure design, installation problem, system problem, how to use the screen…don’t worry, we have professional after-sale team to solve your any questions after you placed an order. And your exclusive sales engineer will also help you get over any problems.
