P3.91 Outdoor Fixed LED Display Aluminum Profile Only 87mm Thick 500x1000mm
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS, EMC |
| Model Number: | P3.91 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 2000sqm/month |
|
Detail Information |
|||
| Product Name: | P3.91 Outdoor Fixed LED Display Aluminum Profile Only 87mm Thick 500x1000mm | Pixel Pitch: | 3.91mm |
|---|---|---|---|
| Cabinet Size: | 500*1000*87mm | Module Size: | 500*250*14mm |
| Cabinet Weight: | 19.5kg/Cabinet | Brightness: | 7500CD/m² |
| IP Rating: | IP65 | Maintenance: | Front/Back |
| Highlight: | P3.91 outdoor LED display aluminum profile,87mm thin fixed LED screen,500x1000mm outdoor LED display |
||
Product Description
P3.91 Outdoor Fixed LED Display Aluminum Profile Only 87mm Thick 500x1000mm
Product Description: High-precision aluminum profile cabinet is only 87mm thick/19.5kg (500×1000mm),500×1000mm and 500×750mm cabinets are free to mix and match shaped shapes, sharing the same type of control box. Push-button lock realizes 5 seconds fast disassembly and assembly, optional arc lock supports curved surface splicing. Fanless ≤ 40dB silent operation, point-by-point calibration to ensure pixel-level uniformity. 3840Hz high refresh to eliminate 1/3000s shutter residual shadow, for stage performances, conferences, to provide a broadcaster-level visual base.
Features
- Point By Point Calibration: Fine-tune the white balance of each lamp bead point by point to eliminate chromatic aberration and light spots, achieve pixel-level display consistency.
- Work In Silence: Fanless silent design, working noise ≤ 40dB (A) ambient sound level.
- Installation And Maintenance: Optional curved locks for 10°~15° and 90° angles; modular push-button locks for 5-second quick assembly and disassembly; optional magnetic modules to support front service & rear service, efficient and convenient assembly and disassembly.
- Cabinets Design: The 500x1000mm and 500x750mm cabinets can be mixed and assembled into a variety of shapes; sharing a simple mini control box saves installation and calibration time.
Technical Parameters
| Item | Specification |
|---|---|
| Pixel Pitch | 3.91mm |
| Resolution rate | 128*64mm |
| Module Size | 500*250*14mm |
| Pixel LED | SMD1921 Black led |
| Module Power | ≤74W |
| Driving IC | ICN2055 |
| Drivingway | 1/8 |
| Material | Aluminum profile |
| Cabinet Weight (kg/Cabinet) | 19.5kg |
| Resolution rate | 128*256Dots |
| Cabinet Size | 500*1000*87mm |
| Module quantity | 1*4 |
| Density | 65536 Dots/㎡ |
| Brightness | 7500CD/m² |
| View Angel | H/V:120°/120° |
| Maximal power/㎡ | ≤650W/㎡ |
| Average Power/㎡ | ≤220W/㎡ |
| Refresh Frequency | 3840Hz |
| Gray Grade | ≥13bit |
| Protection grade | IP65 |
| Maintenance | Front/Back |
Application
- Outdoor creative modeling
- Building entrance
- Park entrance
- Swimming pool
FAQ
Q1: How about your delivery time?
A1: Generally, it will take 15 to 25 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q2: Can you produce according to the samples?
A2: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q3: How can you ensure your led display product quality?
A3: Visual World has been enrolled in led display industry for more than 10 years, and professional R&D team and skilled QC team with standard process to assure quality products.
Q4: What is the control system? How is it?
A4: We use Nova Taurus Series asynchronous control system. Support cluster play and management. Support APP/Phone/WiFi iPad/Laptop/PC/Cloud control. It's very easy and convenient to control.
Q5: What is your best service?
A5: One to one sales engineer to customer responsibility system. We will do:
1. Know your project and provide the best solution for it
2. Track your order and let you know each step and detail of it
3. Teach you how to install and use the screen;
4. Care the subsequent use of your screen and ensure your after-sales service be well
5.6... etc.
1. Know your project and provide the best solution for it
2. Track your order and let you know each step and detail of it
3. Teach you how to install and use the screen;
4. Care the subsequent use of your screen and ensure your after-sales service be well
5.6... etc.
