P3.91 Outdoor Fixed LED Display 500x1000mm Aluminum Profile 7500 nits 19.5kg
P3.91 outdoor LED display
,500x1000mm fixed LED screen
,7500 nits aluminum LED display
P3.91 Outdoor Fixed LED Display 500x1000mm Aluminum Profile 7500 nits 19.5kg
Product Description:
High-precision aluminum profile cabinet is only 87mm thick/19.5kg (500×1000mm),500×1000mm and 500×750mm cabinets are free to mix and match shaped shapes, sharing the same type of control box. Push-button lock realizes 5 seconds fast disassembly and assembly, optional arc lock supports curved surface splicing. Fanless ≤ 40dB silent operation, point-by-point calibration to ensure pixel-level uniformity. 3840Hz high refresh to eliminate 1/3000s shutter residual shadow, for stage performances, conferences, to provide a broadcaster-level visual base.
Features:
- Point By Point Calibration: Fine-tune the white balance of each lamp bead point by point to eliminate chromatic aberration and light spots, achieve pixel-level display consistency.
- Work In Silence: Fanless silent design, working noise ≤ 40dB (A) ambient sound level.
- Installation And Maintenance: Optional curved locks for 10°~15° and 90° angles; modular push-button locks for 5-second quick assembly and disassembly; optional magnetic modules to support front service & rear service, efficient and convenient assembly and disassembly.
- Cabinets Design: The 500x1000mm and 500x750mm cabinets can be mixed and assembled into a variety of shapes; sharing a simple mini control box saves installation and calibration time.
Technical Parameters:
| Item | Specification Parameter |
| PixelPitch | 3.91mm |
| Resolution rate | 128*64mm |
| Module Size | 500*250*14mm |
| Pixel LED | SMD1921 Black led |
| Module Power | ≤74W |
| Driving IC | ICN2055 |
| Drivingway | 1/8 |
| Material | Aluminum profile |
| Cabinet Weight (kg/Cabinet) |
19.5kg |
| Resolution rate | 128*256Dots |
| Cabinet Size | 500*1000*87mm |
| Module quantity | 1*4 |
| Density | 65536 Dots/㎡ |
| Brightness | 7500CD/m² |
| View Angel | H/V:120°/120° |
| Maximal power/㎡ | ≤650W/㎡ |
| Average Power/㎡ | ≤220W/㎡ |
| Refresh Frequency | 3840Hz |
| Gray Grade | ≥13bit |
| Protection grade | IP65 |
| Maintenance | Front/Back |
Application:
- Outdoor creative modeling
- Building entrance
- Park entrance
- Swimming pool
FAQ
Q1:Can you give me a discount?
A1:Yes, based on wholesale service, we have better discount for bigger quantities. We will quote you the best price based on your order quantity.
Q2: Is your company a real manufacturer?
A2: Our company is a professional factory , located in Baoan district, Shenzhen city, China. You are the mostly welcomed to visit our factory anytime.
Q3: How is the quality of the product?
A3: Our products have been strictly tested high quality by QC before shipping to customers.We are adhering to the principle:
"Quality and service are our first priority."
Q4: What pixel pitch should I choose on my display?
A4: It mainly depends on the viewing distance, the size of the display, the desired effect and the customer's budget.
Q5: What if I don't know how to maintain the screen?
A5: When you place your order, we will provide you with the operating manual and software, and we can help you remotely adjust the software through the team.
Q6:Can you provide free spare parts?
A6:A certain amount of spare parts will be provided for free, spare parts including module,power cable,signal cable,LED lamp,lC,mask, power supply, receiving card. etc.
-
