P6.25 Outdoor Fixed LED Display Better Heat Dissipation For Pedestrian Street
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS, EMC |
| Model Number: | P6.25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 2000sqm/month |
|
Detail Information |
|||
| Product Name: | P6.25 Outdoor Fixed LED Display Better Heat Dissipation For Pedestrian Street | Pixel Pitch: | 6.25mm |
|---|---|---|---|
| Module Size: | 500*250mm | Cabinet Dimension: | 1000*1000mm/1000*500mm/1000*750mm/1500*1000mm/1500*500mm |
| Cabinet Weight: | 30kg/Cabinet | Maintenance: | Front/Rear Service |
| IP Rating: | IP65 | Brightness: | 6000/9000nits |
| Highlight: | P6.25 outdoor LED display,fixed LED screen for pedestrian street,heat dissipation outdoor LED display |
||
Product Description
P6.25 Outdoor Fixed LED Display Better Heat Dissipation For Pedestrian Street
Product Description
The P6.25 Outdoor Fixed LED Display ensures reliability and high performance through its robust installation design, employing a hub connection to reduce failure rates and a 500 x 250mm aluminum backplate to prevent deformation while enhancing thermal management. It enables both front and rear maintenance, includes an IP65 waterproof rating, and integrates a 2+1 power connector to avoid overheating risks. Optional smart modules with common cathode or anode configurations further extend adaptability for varied application demands.
Key Features
- Waterproof: Durable, waterproof, fast heat dissipation aluminum cabinet with IP65 protection level for outdoor use.
- Front & Rear Service: Can be installed against the wall, with full front and rear maintenance design, convenient installation and saving installation space.
- Better Heat Dissipation: After one hour of white balance illumination, the aluminum base demonstrates superior heat dissipation, registering a temperature 10 degrees lower than a plastic base.
- Wide Viewing Angles: Horizontal 140°, vertical 140° allows audience to watch the screen clearly from distances.
- 2+1 Power: The 2+1 power connector design features a built-in anti-reverse insertion mechanism to avoid damage from incorrect connections, precisely meets current load requirements for stable power delivery, and ensures safe, reliable module operation even under fluctuating electrical conditions.
Technical Specifications
| Item | P6.25 |
|---|---|
| Pixel Pitch | 6.25mm |
| Module Size | 500*250mm |
| Cabinet Dimension | 1000*1000*90mm/1000*500*90mm/1000*750*90mm/1500*1000*90mm/1500*500*90mm |
| LED Type | SMD2727 |
| Scan Mode | 1/5 |
| Cabinet Material | Aluminum Profile |
| Cabinet Weight | 30kg/cabinet |
| Brightness | 6000/9000nits |
| Power Consumption | 600/210w/m2 |
| Maintenance | Front/Rear Service |
| IP Rating | IP65 |
| Refresh Rate | ≥3840Hz |
| Viewing Angle | H:140°; V:140° |
| Operational Temp | ﹣20~50℃ |
| Operational Humidity | 10%~90%RH |
Applications
- Outdoor creative modeling
- Building entrance
- Park entrance
- Swimming pool
- Advertising billboard
- Playing field
- Outdoor activity area
- Roadside poster
- Building exterior wall
Frequently Asked Questions
Q1: Are you a factory or trading company?
A1: 100% factory. We have more than 10 years of manufacturing experience. OEM & ODM order is warmly welcomed.
Q2: Why purchase from Visual World?
A2: Stable and reliable quality, efficient and professional customer service, competitive factory price, fast delivery time.
Q3: What's your delivery time?
A3: 7-15 days according to order quantity and season.
Q4: Do you have any MOQ limit for LED display order?
A4: Low MOQ, 1 square meter or a module checking is available.
Q5: What is the payment term?
A5: We accept T/T, Western Union, PayPal, Credit card etc.
Q6: How long is the warranty?
A6: One year, two years, three years warranty or life long after service. Normal warranty 1 year, any special requests please contact us.
Q7: To order a display, what kind of information do I have to offer you?
A7: You should provide width/height of the display, the main use, the viewing distance, the scene photos, special requirements, then I can provide you with a detailed list of quotations.
