P5 Outdoor Fixed LED Display16:9 Gold Ratio Module Magnet Design 5500nits
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS, FCC |
| Model Number: | P5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, flight case |
| Delivery Time: | 10 work days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 3000sqm/month |
|
Detail Information |
|||
| Product Name: | P5 Outdoor Fixed LED Display16:9 Gold Ratio Module Magnet Design 5500nits | Pixel Pitch: | 5 Mm |
|---|---|---|---|
| LED Type: | SMD1921 | Cabinet Dimension: | 960×540 Mm |
| Brightness: | 5500nits | IP Rating: | IP65 |
| Cabinet Weight: | 13kg | Maintenance: | Front Service |
| Cabinet Material: | Aluminum Profile | Driving Type: | 1/9 |
| Highlight: | P5 outdoor LED display,16:9 gold ratio LED screen,5500nits fixed LED display |
||
Product Description
P5 Outdoor Fixed LED Display16:9 Gold Ratio Module Magnet Design 5500nits
P5 Outdoor Fixed LED Display is a robust and high-performance display solution designed for outdoor environments where durability and visual excellence are paramount. This display module, measuring 960mm by 540mm, is meticulously crafted with an aluminum profile that not only ensures structural integrity but also contributes to its lightweight and sleek design.
Features
- 16:9 Gold ratio: Module size:480*270mm; Cabinet size:960*540mm
- Thin and light: Single cabinet 11.5kg, thickness 58mm
- Module magnet design: Power box can be individually removed
- Modular design: Front service
- Quick and easy installation
Technical Parameters
| Technical Parameters | Outdoor Fixed LED Display Screen |
|---|---|
| Pixel Pitch: | 5 mm |
| LED Type: | SMD1921 |
| Cabinet Dimension: | 960×540 mm |
| Module Size: | 480x270 mm |
| Cabinet Weight: | 13kg |
| Cabinet Material: | Aluminum Profile |
| Driving Type: | 1/9 |
| Brightness: | 5500 nits |
| Max/Avg Power: | 720/252 W/m2 |
| Maintenance: | Front service |
| IP Rating: | IP65 |
| Refresh Rate: | >3840 Hz |
| Installation Type: | Mounting/Hanging |
| Gray Scale: | 14 bit |
| Viewing Angle: | H:140°；V:140° |
| Operational Temp: | -20℃~+50℃ |
| Operational Humidity: | 10%~90% RH |
Applications
- Outdoor Advertising: The high brightness and weather resistance make it perfect for outdoor advertising billboards, capturing the attention of passersby.
- Public Information Displays: Ideal for displaying real-time information in public spaces such as squares, parks, and transportation hubs.
- Branding and Identity: Use the display to showcase brand messages and identity elements with high visual impact in outdoor commercial spaces.
- Live Events: Enhance the visibility of event information and promotions at concerts, sports events, and trade shows.
Installation
Installation of Outdoor LED display
FAQ
Q1: LED display models are generally expressed in PX, such as P2 P3 P4.....P8, P10, what does this mean?
A1: P3 P4.....P8,P10 means that the pixel pitch is 3mm 4mm....10mm, which determines resolution of a display. Pixel pitch is smaller, led display resolution is higher.
Q2: What pixel pitch should I choose on my display?
A2: It is determined mainly by the viewing distance, the size of the display screen, the desired effect and the customer budget.
Q3: To order a display, what kind of information do I have to offer you?
A3: You should provide width/height of the display, the main use, the viewing distance, the scene photos, special requirements, then I can provide you with a detailed list of quotations.
Q4: How to install?
A4: Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram, free remote debugging. We can also send our engineers to the site to guide the installation if needed.
Q5: Can I order a sample?
A5: Yes, We welcome customers to order samples to check our product quality of our products and service.
