P1.875 Small Pixel Pitch LED Display 5.5 kg Cabinet 600×337.5mm For Indoor
Product Details:
| Place of Origin: | CN |
| Brand Name: | Visual World |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | FP1.875 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | 12 work days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 sqm/month |
|
Detail Information |
|||
| Product Name: | P1.875 Small Pixel Pitch LED Display 5.5 Kg Cabinet 600×337.5mm For Indoor | Pixel Pitch: | 1.875mm |
|---|---|---|---|
| Cabinet Material: | Die-casting Aliuminum | Cabinet Size: | 600×337.5×58 Mm |
| Maintenance: | Front Service | Brightness: | 600 Nits |
| Cabinet Weight:: | 5.5kg | IP Rating: | F: IP30, R: IP45 |
| Highlight: | P1.875 COB LED display indoor,small pixel pitch LED display 600×337.5mm,lightweight COB LED display 5.5 kg |
||
Product Description
P1.875 Small Pixel Pitch LED Display 5.5 kg Cabinet 600×337.5mm For Indoor
The P1.875 Small Pixel Pitch LED Display delivers exceptional visual performance with ultra-fine detail and vibrant color reproduction. Its optimized 16:9 aspect ratio ensures broad viewing angles and comfortable immersion for all audiences. The integrated control system simplifies operation, while the full front-access maintenance design enables effortless servicing--keeping the display at peak performance with minimal downtime.
Key Features
- Full flip-chip COB process with protection technologies including anti-collision, waterproofing, moisture resistance, and salt spray resistance
- 3D ink printing technology enhances contrast by 20% and lowers display brightness requirements
- LCD status display panel for real-time monitoring of cabinet operations
- HDI multi-layer circuit board design ensures excellent color uniformity and even temperature distribution
- Energy-efficient common cathode chip with grayscale levels up to 16-bit
Technical Specifications
| Product Model | FP1.875 |
|---|---|
| Pixel Pitch | 1.875mm |
| LED Type | SMD1515 |
| Cabinet Dimension | 600x337.5x58mm |
| Module Size | 300x168.75 mm |
| Cabinet Weight | 5.5 kg |
| Cabinet Material | Die-casting Aluminum |
| Brightness | 600 nits |
| Max/Avg Power | 450/135 W/m² |
| Refresh Rate | >3840 Hz |
| Viewing Angle | H:140°; V:140° |
| Operational Temp | -20℃~+50℃ |
Applications
- Digital Signage systems
- Chain stores
- Billboards
- Perimeter LED posters
- Arena displays
Support and Service
Pre-sales: Detailed production instructions and professional installation guidance
Sales: Customized solutions, visual designs, and project showcases
After-sales: Two-year warranty, professional maintenance team, timely assistance, spare parts provision, free training, logistics tracking, and continuous software improvement
Sales: Customized solutions, visual designs, and project showcases
After-sales: Two-year warranty, professional maintenance team, timely assistance, spare parts provision, free training, logistics tracking, and continuous software improvement
Frequently Asked Questions
Q: Can you accept sample orders?
A: Yes, sample orders are acceptable for quality checks and market testing.
Q: What LED screen sizes can you provide?
A: Screen sizes can be customized based on your requirements.
Q: What is the warranty period?
A: We provide a two-year warranty for all products.
Q: How do you guarantee product quality?
A: We implement rigorous quality control at every production stage, including component selection, advanced manufacturing, and comprehensive testing. Each display undergoes meticulous final inspection before shipment.
Q: How quickly can you provide technical support?
A: We provide professional technical support within 24 hours of receiving notification.
