P3.9 Holographic Transparent LED Screen Display Rear Service 6kg/SQM For Galleries
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P3.9 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case, flight case |
| Delivery Time: | 5-10 days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Supply Ability: | 3000sqm/month |
|
Detail Information |
|||
| Product Name: | P3.9 Holographic Transparent LED Screen Display Rear Service 6kg/SQM For Galleries | Brightness: | 1000-5000nits |
|---|---|---|---|
| Waterproof: | IP42 | Led Type: | SMD1415 1R1PG1PB UV |
| Driving Method: | Static | Transparent Rate: | 70% |
| Maintenance: | Rear Service | Cabinet Size: | 600/1200/1800x500/600/700/800mm |
| Cabinet Material: | Aluminum+PCB | Panel Weight: | 6 Kg/sqm |
Product Description
P3.9 Holographic Transparent LED Screen Display Rear Service 6kg/SQM For Galleries
Product Description:
P3.9 Indoor Holographic Transparent LED Display is an innovative display solution designed for indoor applications that require a high level of visual engagement without compromising on aesthetics or space. This lightweight display system, weighing only 6kg per square meter, offers a perfect blend of technology and design.
Features:
-
Transparent:Industry premiere,with no structural backbone；Real fully transparent；Permeability can reach 70%
- Thin:Module thickness<3mm；Seamless curved surface mountingIntegrated seamlessly onto glass
- Foldable and arbitrarytransformation shape；Soft and bendable.lt can becustomized into different shapes according to different scenes, for example,triangles, ellipses, etc.
- Arbitrary cutting,seamless spiced display:The screen size can be arbitrarily cropped, the closer the distance betweenthe screen beads of the seamless splicing screen, the clearer the pixeldensity. And the seamless cropped screen is more flexible to match theinstallation and regional carrier.
Technical Parameters:
| Pixel Pitch (H/V) | W:3.9;H:3.9mm | W:6.25;H:6.25mm |
| LED Configuration | SMD1415 1R1PG1PB UV | SMD1415 1R1PG1PB UV |
| Pixel Density | 65536dot/㎡ | 25600dot/㎡ |
| Transparency | <66.66% | <70% |
| Drive Scheme | 18 aisle | 18 aisle |
| Scan method | 0 Scan(6 layer PCB) | 0 Scan(4 layer PCB) |
| Refresh Rate | 1920-3840Hz | 1920-3840Hz |
| Module Size | 375/750/1125/1500X125mm(L/R) | 600/1200/1800X100mm(L/R) |
| Module Resolution | 96/192/288/384X32dot | 96/192/288X16dot |
| Product Size | 375/750/1125/1500X500mm | 600/1200/1800X500/600/700/800mm |
| Cabinet Resolution | 96/192/288/384X128dot | 96/192/288X80/96/112/128dot |
| Cabinet Weight | 6kg/㎡ | 6kg/㎡ |
| IP Rating ( front/back) | IP42 | IP42 |
| Brightness | 1000-5000nits/㎡ | 1000-5000nits/㎡ |
| Viewing Angle (H/V) | 140°/140° | 140°/140° |
| Viewing Distance | 4m | 6 m |
| Gray Scale | 16 bit | 16 bit |
| Max.Power Consumption | 800W/m² | 800W/m² |
| Ave.Power Consumption | 240W/m² | 240W/m² |
| Maintenance | Rear service | Rear service |
| Environment | indoor | indoor |
| Operation Power | AC:100_240V;50/60Hz | AC100_240V,50/60Hz |
| Operating Temperature | ﹣10℃~40℃ (work) | ﹣10℃~40℃ (work) |
| Operating Humidity | 35%～85% (work),10%～90% | 35%～85% (work),10%～90% |
| Operating Life | 100,000hours | 100,000hours |
Applications:
-
Retail Displays: Enhance product showcases with dynamic holographic displays that capture the attention of shoppers and provide an immersive shopping experience.
-
Galleries and Exhibitions: Provide a unique viewing experience for art and exhibits, allowing visitors to see the artwork in a new light.
-
Corporate Settings: Use in conference rooms and lobbies for impactful presentations and informational displays that leave a lasting impression.
-
Entertainment Venues: Create immersive environments in theaters, clubs, and other entertainment spaces, adding depth and excitement to the atmosphere.
FAQ:
Q1: What can you buy from us?
A1: Rental LED Display, Outdoor LED Display, Indoor LED Display, Transparent LED Screen, Floor Tile Screen, Creative Design LED Screen and Etc.
Q2: Can I customize it?
A2: Of course. All the goods can be customized, we have a professional product development team, welcome to customize.
Q3: What is Price per square meter of screen?
A3: Welcome to send us inquiry. Our professional sales engineers will provide suitable solutions.
Q4: How many days for producing?
A4: 1-3 days for inventory products and 10-15 days for customized products.
Q5: How to operate and use it?
A5: It can by controlled by PC and Smartphone very easily.
Welcome to inquiry for more information. We provide video guidance and remote assistance.
