P0.9 Small Pixel Pitch LED Display COB 600-2000nits Brightness And High Reliability
Product Details:
| Place of Origin: | CN |
| Brand Name: | Visual World |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P0.9 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | 12 work days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 sqm/month |
|
Detail Information |
|||
| Product Name: | P0.9 Small Pixel Pitch LED Display COB 600-2000nits Brightness And High Reliability | Pixel Pitch: | P0.7/P0.9/P1.25/P1.56 |
|---|---|---|---|
| Cabinet Material: | Die-casting Aliuminum | Size: | 600x337.5mm |
| Maintenance: | Front/Rear Service | Brightness: | 600-2000nits |
| Refresh Rate: | ＞3840Hz | Durability: | 100000 Hours |
| Highlight: | COB Small Pixel Pitch LED Display |
||
Product Description
P0.9 Small Pixel Pitch LED Display COB 600-2000nits Brightness And High Reliability
Product Description:
Features:
- High Brightness: brightness up to 1000nits.
- Energy-saving: Energy saving 30%.
- High Reliability: Flip-chip common cathode, better heat dissipation, and more stable.
- Patented Appearance Treatment: No white edge and burrs of the module; Light transmittance up to 75% and Low temperature.
- High Contrast Ratio: >20000:1.
- High Consistency: Micro LED Flip-chip mixed processing technology & same Bin chips.
- Wide Color Gamut: DCl-P3 wide color gamut.
- Easy Installation: Full front maintenance, multiple disassembly, and assembly of LED modules without white edges.
- Various Applications: Support wall-mounted installation, floor-standing, and hanging installation.
Technical Parameters:
| Model | P0.9 |
| Pixel Pitch | 0.9mm |
| LED Type | COB |
| Cabinet Dimension | 600*337.5*35mm |
| Module Size | 150x168.75 mm |
| Cabinet Weight | 4.6kg |
| Cabinet Material | Die-casting Aluminum |
| Driving Type: | 1/36 |
| maintenance | Front service |
| Brightness | 600-2000 nits |
| Max/Avg Power | 420/147 W/m2 |
| IP Rating |
Front: IP65 / Rear: IP30 |
| Refresh Rate | >3840Hz |
| Installation Type |
Mounting / Hanging / Stacking |
| Gray Scale | 16bit |
| Viewing Angle | H:170°；V:170° |
| Operational Temp | -20℃~+50℃ |
| Operational Humidity | 10%-90%RH |
Applications:
- Digital Signage system
- Chain store
- Street furniture
- Billboard
- Football stadium
- Perimeter LED poster
- Arena display, etc.
Pre-Sale Services:
- Prompt responses to inquiries within 24 hours.
- Market analysis and forecasting assistance.
- Tailored solutions to meet specific customer requirements.
- Provision of data sheets and product samples.
- Additional support, including custom packaging and factory tours.
In-Sale Services:
- Ongoing monitoring of the production process.
- Production updates with photos and videos upon request.
- Complimentary spare parts are included.
After-Sale Services:
- Resolution of complaints within 24 hours.
- Maintenance support and solutions are provided within 48 hours.
- 24-month warranty coverage.
- Free technician training sessions.
- Complimentary documentation, including installation guides, software manuals, maintenance guides, and control system software CDs.
FAQ:
Q1: Can you accept the sample orders?
A1: Yes, we accept sample orders for quality verification and market testing.
Q2: Does there have any warranty?
A2: Yes, a two-year warranty for all products.
Q3: Can I customize it?
A3: Of course. All the goods can be customized, we have a professional product development team, welcome to customize.
Q4: What is your MOQ?
A4: Any quantity is acceptable for your order. And the price is negotiable for large quantities.
Q5: Can it play HD video?
A5: Yes, it can realize HD video function with Novastar or Colorlight controlling system.
Q6: How can we guarantee quality?
A6: Always a pre-production sample before mass production; Always final Inspection before shipment.
