Stage Background Led Display High Operational Range with 5500nits Brightness and SMD1415 SMD1921 LED Type
Product Details:
| Place of Origin: | China |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P2.5 P3 P4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | less than 6 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000sqm per month |
|
Detail Information |
|||
| Product Name: | Stage Background Seamless And Vibrant Led Display With High Operational Range | Cabinet Material: | Aliuminum Profile |
|---|---|---|---|
| Cabinet Size: | 1000x1000x90mm | Cabinet Weight: | 30kg/sqm |
| Lifespan: | 100000 Hours | Brightness: | 5500nits |
| Ip Rating: | IP65 | LED Type: | SMD1415 SMD1921 |
| Installation Type: | Mounting Hanging | Gray Scale: | 14 Bit |
| Highlight: | SMD1415 SMD1921 LED Display,High Operational Range Led Display,5500nits Brightness Led Display |
||
Product Description
Stunning Vision Outdoor LED Screen With SMD Light And IP65 High Protection
Product Description:
The Stunning Vision Outdoor LED Screen, featuring SMD technology and IP65 protection, delivers high-performance outdoor advertising. Its 5500 nits brightness ensures vibrant visuals in any weather, making it ideal for large-scale digital displays.
Features:
-
Flexible Installation Options:
Supports mounting and hanging installations, catering to diverse project requirements. -
Superior Image Quality:
14-bit grayscale for enhanced color depth and image clarity. -
Wide Viewing Angles:
Horizontal viewing angle of 140° and vertical viewing angle of 120°, ensuring visibility from different directions. -
Operational Resilience:
Temperature range: Operates reliably in extreme temperatures from -20°C to +60°C.
Humidity tolerance: Supports operational humidity levels between 10% and 90%. - Removed redundancy: Phrases like "high-performance solution" and "designed for outdoor advertising" are often implied.
- Enhanced flow: The sentences are restructured for better readability.
- Stronger word choices: Words like "deliver," "boast," and "captivating" add impact.
- Conciseness: Unnecessary words and phrases are removed to improve clarity.
Technical Parameters:
| Product Model: | P2.5 | P3 | P3.076 | P3.33 | P3.33 | P4 | P4 |
| Pixel Pitch: | 2.5mm | 3mm | 3.076mm | 3.33mm | 3.33mm | 4mm | 4mm |
| LED Type: | SMD1415 | SMD1415 | SMD1415 | SMD1921 | SMD1921 | SMD1921 | SMD1921 |
| Cabinet Dimension: | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 1024x1024mm | 960x960mm |
| Module Size: | 160×160mm | 192×192mm | 192×192mm | 160×160mm | 320×160mm | 256×128mm | 320×160mm |
| Maintenance | Rear service | ||||||
| Cabinet Weight: | 38 kg | ||||||
| Cabinet Material: | Steel | ||||||
| Driving Type: | 1/16 | 1/16 | 1/13 | 1/12 | 1/12 | 1/8 | 1/10 |
| Brightness: | 5500 nits | ||||||
| Max/Avg Power: | 800/280 W/㎡ | ||||||
| Environment: | Outdoor | ||||||
| IP Rating: | IP65 | ||||||
| Refresh Rate: | >1920 Hz | ||||||
| Installation Type: |
Mounting/Hanging |
||||||
| Gray Scale: | 14 bit | ||||||
| Viewing Angle: | H:140°；V:120° | ||||||
| Operational Temp: | -20℃~+60℃ | ||||||
| Operational Humidity: | 10%~90% RH | ||||||
Application:
For Entertainment
For Advertising In SuperMarket
For Advertising In Suburbs
FAQ:
Q1: What control system is used, and how does it work?
A1: We use the Nova Taurus Series asynchronous control system, which supports cluster playback and management. You can easily control it via various devices, including APP, smartphone, Wi-Fi, iPad, laptop, PC, or through cloud control. It's very user-friendly and convenient.
Q2: Can I place a sample order for an LED screen?
A2: Yes, we encourage sample orders for testing and quality evaluation. Mixed samples are also accepted.
Q3: Can I have my logo printed on the product?
A3: Absolutely. Please let us know in advance and confirm the design based on our sample before production begins.
Q4: What is your delivery time?
A4: Typically, delivery takes 7-15 days after the deposit is received. However, the exact time depends on the order size and items.
Q5: What is your warranty policy?
A5: We offer a 2-year warranty. We also provide full support for structure design, installation issues, system troubleshooting, and screen usage.
Our professional after-sales team, along with your dedicated sales engineer, will assist with any questions you may have after your order.
