Outdoor LED Screen XTRAVIEW – For extreme viewing quality, high brightness, and refresh rate.
Product Details:
| Place of Origin: | China |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P2.5 P3 P4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | less than 6 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000sqm per month |
|
Detail Information |
|||
| Product Name: | IP65 Outdoor Fixed LED Display Screen With High Refresh Rate And Large Viewing Scale | Cabinet Material: | Aliuminum Profile |
|---|---|---|---|
| Cabinet Size: | 1000x1000x90mm | Cabinet Weight: | 30kg/sqm |
| Lifespan: | 100000 Hours | Operation Temperature: | -20°C To +60°C |
| Operation Hudmidity: | 10 % - 90% RH | Ip Rating: | IP65 |
| Brightness: | 5500nits | LED Type: | SMD1415 SMD1921 |
| Installation Type: | Mounting Hanging | ||
| Highlight: | High Brightness Outdoor LED Screen,Outdoor LED Screen XTRAVIEW |
||
Product Description
Outdoor LED Screen – For extreme viewing quality, high brightness, and refresh rate.
Product Description:
Whether used for stadiums, outdoor advertising, public spaces, or live events, XTRAVIEW sets a new standard in LED displays by delivering exceptional brightness, reliability, and durability—transforming every viewing experience into an unforgettable visual journey.
Features:
Key Features of the LED Display:
-
Outdoor Durability
- Designed for outdoor environments, XTRAVIEW’s IP65 rating protects against dust and water, ensuring consistent performance in various weather conditions.
-
Efficient Rear Serviceability
- Built with rear-service access, XTRAVIEW allows for efficient maintenance, reducing downtime and making upkeep simple and cost-effective.
-
Rugged and Reliable Construction
- The cabinet is constructed from durable steel and weighs 38 kg, providing a robust build that withstands outdoor conditions while offering stability for long-term installations.
-
Flexible Power Management
- Optimized for energy efficiency, XTRAVIEW has a maximum power consumption of 800 W/m² and an average of 280 W/m², making it an economical choice for high-impact visual displays.
Technical Parameters:
| Product Model: | P2.5 | P3 | P3.076 | P3.33 | P3.33 | P4 | P4 |
| Pixel Pitch: | 2.5mm | 3mm | 3.076mm | 3.33mm | 3.33mm | 4mm | 4mm |
| LED Type: | SMD1415 | SMD1415 | SMD1415 | SMD1921 | SMD1921 | SMD1921 | SMD1921 |
| Cabinet Dimension: | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 960x960mm | 1024x1024mm | 960x960mm |
| Module Size: | 160×160mm | 192×192mm | 192×192mm | 160×160mm | 320×160mm | 256×128mm | 320×160mm |
| Maintenance | Rear service | Rear service | Rear service | Rear service | Rear service | Rear service | Rear service |
| Cabinet Weight: | 38 kg | 38 kg | 38 kg | 38 kg | 38 kg | 38 kg | 38 kg |
| Cabinet Material: | Steel | Steel | Steel | Steel | Steel | Steel | Steel |
| Driving Type: | 1/16 | 1/16 | 1/13 | 1/12 | 1/12 | 1/8 | 1/10 |
| Brightness: | 5500 nits | 5500 nits | 5000 nits | 5500 nits | 5500 nits | 6500 nits | 5500 nits |
| Max/Avg Power: | 800/280 W/m2 | 800/280 W/m2 | 800/280 W/m2 | 800/280 W/m2 | 800/280 W/m2 | 800/280 W/m2 | 800/280 W/m2 |
| Environment: | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor |
| IP Rating: | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Refresh Rate: | >1920 Hz | >1920 Hz | >1920 Hz | >1920 Hz | >1920 Hz | >1920 Hz | >1920 Hz |
| Installation Type: |
Mounting /Hanging |
Mounting /Hanging |
Mounting /Hanging |
Mounting /Hanging |
Mounting /Hanging |
Mounting /Hanging |
Mounting /Hanging |
| Gray Scale: | 14 bit | 14 bit | 14 bit | 14 bit | 14 bit | 14 bit | 14 bit |
| Viewing Angle: | H:140°；V:120° | H:140°；V:120° | H:140°；V:120° | H:140°；V:120° | H:140°；V:120° | H:140°；V:120° | H:140°；V:120° |
| Operational Temp: | -20℃~+60℃ | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor |
| Operational Humidity: | 10%~90% RH | 10%~90% RH | 10%~90% RH | 10%~90% RH | 10%~90% RH | 10%~90% RH | 10%~90% RH |
Application:
For Entertainment
For Advertising In SuperMarket
For Advertising In Suburbs
FAQ:
Q1: What control system is used, and how does it work?
A1: We use the Nova Taurus Series asynchronous control system, which supports cluster playback and management. You can easily control it via various devices, including APP, smartphone, Wi-Fi, iPad, laptop, PC, or through cloud control. It's very user-friendly and convenient.
Q2: Can I place a sample order for an LED screen?
A2: Yes, we encourage sample orders for testing and quality evaluation. Mixed samples are also accepted.
Q3: Can I have my logo printed on the product?
A3: Absolutely. Please let us know in advance and confirm the design based on our sample before production begins.
Q4: What is your delivery time?
A4: Typically, delivery takes 7-15 days after the deposit is received. However, the exact time depends on the order size and items.
Q5: What is your warranty policy?
A5: We offer a 2-year warranty. We also provide full support for structure design, installation issues, system troubleshooting, and screen usage.
Our professional after-sales team, along with your dedicated sales engineer, will assist with any questions you may have after your order.
