P5.71 Aluminum Profile 960x960mm Outdoor Fixed LED Display Screen with 2 Years Warranty

P5.71 Aluminum Profile 960x960mm Outdoor Fixed LED Display Screen with 2 Years Warranty

Product Details:

Place of Origin: CN
Brand Name: VW
Certification: CE, ROHS, LVD, EMC
Model Number: P5.71

Payment & Shipping Terms:

Minimum Order Quantity: Negotiate
Price: Negotiate
Packaging Details: Plywood case
Delivery Time: 8-10 work days
Payment Terms: T/T, Western Union, D/P
Supply Ability: 2000 sqm/month
Get Best Price Contact Now

Detail Information

Chip Color: Full Color Usage: Outdoor
Pixel Density: 30625 Dots/sqm Function: Module Flash, Synchronous/asynchronous Control, Flame Retardancy
Application: Roadside, Building Facade, Street Module Connection: Hard Connection
Warranty: 2 Years Lifespan: 100000 Hours
High Light:

Aluminum Profile LED Display Screen

,

P5.71 Outdoor Fixed LED Display

Product Description

P5.71 Aluminum Profile 960x960mm Outdoor Fixed LED Display Screen with 2 Years Warranty



Product Description:

New outdoor front rear service display made of aluminum profile frame, high precision, concise modeling, mature industrial structure design. Easy to transport and install. New trend of outdoor led display comparing to conventional clumsy cabinet, it combines safety, stability, durability



Product Quick Details:

1. Dual Port Module

2. Front / Rear Service

3. IP66 Protection

4. Fast Heat Dissipation

5. Hard Connection





Features:

Visual World redesign and simplify the module and cabinet separately from the traditional outdoor bulky cabinets, in order to achieve improvements in appearance and functionality. Customized modules equip with unusual size 480x320mm, and enable it to work independently waterproof. The appearance and function of the cabinet are optimized, achieving a lightweight and easy installing effect. Visual World maximizes the efficiency of outdoor display screen assembly, leading a new trend in the future outdoor fixed installation market.



In order to improve the led display's appearance and functionality, Visual World redesigns and simplifies it apart from the conventional outdoor bulky cabinets. Customized modules come with an uncommon size of 480x320mm and are waterproof. The cabinet's appearance and functionality have been optimized for lightness and ease of installation. By maximizing the effectiveness of outdoor display screen assembly, Visual World is setting a new standard in the industry for fixed outdoor installations.



1. DUAL PORT MODULE

Modules have 2 ports for connecting and both can use, so there won’t be left and right side to choose when doing installation or repairing.



2. FRONT REAR SERVICE

Module and power box are reachable from front or rear side, convenient to use and meet different kinds of project conditions.



3. WATERPROOF

Up to IP66 protection level for outdoor using. Durable and stable.



4. FAST HEAT DISSIPATION

Whole frame is made of aluminum profile, and no closed structure for the modules. Let the heat goes through the frame and module itself, extend the life time of the led display.



5. HARD CONNECTION

Modules connect to the hub board directly to communicate without cables. Convenient and fast, accurate positioning, no cables need to organize.



Technical Parameters:

Product Model: FIA-Outdoor
Pixel Pitch: 5.71 mm
LED Type: SMD2727
Cabinet Dimension: 960x960 mm
Cabinet Resolution: 168*168 pixels
Module Size: 480x320 mm
Module Resolution: 84*56 pixels
Module Qty/cabinet: 2x3=6pcs
Pixel Density: 30625 dots/sqm
Cabinet Weight: 22 kg
Cabinet Material: Aluminum profile
Cabinet Color: Black / White
Driving Type: 1/7
Brightness: 6000 nits
Max/Avg Power: 600/170 W/m2
Maintenance: Front rear service
Environment: Outdoor Use
IP Rating: IP66
Refresh Rate: >3840 Hz
Installation Type: Mounting/Stacking
Gray Scale: 14 bits
Viewing Angle: H:140°;V:140°
Operational Temp: -20℃~+50℃
Operational Humidity: 10%~90% RH



Applications:

Highway billboard

Pole LED wall

outdoor advertising

Roadside poster

Sport stadium

P5.71 Aluminum Profile 960x960mm Outdoor Fixed LED Display Screen with 2 Years Warranty 0P5.71 Aluminum Profile 960x960mm Outdoor Fixed LED Display Screen with 2 Years Warranty 1



Accessories

Novastar/Colorlight led controller

Spare led module

Power supply

Receiving card

Main signal cable

Main power cable

Metal connector

Screws

Front service tool

Light sensor



Our Service:

Pre-sale service:

Inquiries will be replied within 24 hours. Market research and forecast for customer. Provide unique and professional solutions based on customer's requirement. Data sheet and samples offered. Other required services such as special packing design, factory visiting and so on.



In-sale service:

Tracking producing procedures all the time. Provide photos and videos as per customer's requirement during production. Free spare parts provided.



After-sale service:

Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours. Warranty: 24 months. Free technician training. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.



P5.71 Aluminum Profile 960x960mm Outdoor Fixed LED Display Screen with 2 Years Warranty 2

FAQ

Q1. Who is Visual World?

Visual World is a modern factory dedicated to applying artificial intelligence to the LED industry. In terms of product selection, we use big data to analyze the traditional LED display industry based on AI technology, and select the most popular LED products in the market for R&D and promotion.



Q2. Why choose Visual World?

-More than 20,000 square meters of industrial area

-Complete production equipment, including SMT machines, temperature furnaces, LED dead pixel detectors, screw fixing machines, packing machines, aging racks, assembly lines, and various test equipment, including test equipment for salt spray, temperature impact, vibration, and waterproofness.

-Senior technical and sales teams with over 20 years of industry experience

-Rich project experiences with thousands of instances around the globe

-Product certifications include CE, ROHS, EMC, LVD, ETL, and FCC Online technical assistance is available around-the-clock



Q3. What led brand do you use for this model?

We use high quality SMD LED like Nationstar which has stable quality and longer lifespan for this led screen.



Q4. It is CE certificated?

Yes, we have CE, RoHS, EMC-A certificated for all the outdoor led display products.



Q5. You provide the structures on site?

Yes, we do. But we didn’t recommend to product it in our factory, since the delivery fee for structures will be extremely high. We can make the structure drawings for you, and suggest to produce the structure and install it on your side.
