P3.9 Smart Outdoor LED Display Module IP67 Power Signal Integration 250x500mm
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS |
| Model Number: | Smart Block Plus |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood box |
| Delivery Time: | 15 days |
| Payment Terms: | T/T |
| Supply Ability: | 1500sqm/month |
|
Detail Information |
|||
| Refresh Rate: | 3840Hz | Operating Temperature: | -20°C~50°C |
|---|---|---|---|
| Power Consumption: | 600W/㎡ | Operating Humidity: | 10%~90% |
| Installation Method: | Wall Mounted/Hanging | Input Voltage: | AC220V/50Hz |
| Module Size: | 250mm*500mm | Brightness: | 4000cd/m2 |
| IP Rate: | IP67 | Material: | Aluminum |
| Connection: | Hard Connection | ||
| High Light: | P3.9 Outdoor LED Display Module,Outdoor LED Display Module IP67,250x500mm outdoor display module |
||
Product Description
IP67 Outdoor P3.9 LED Smart Module Power Signal Integration 250x500mm
Product Description:
Our SMART BLOCK-PLUS series Outdoor LED Display Module is designed to meet a wide range of outdoor applications. This module is 250mm*500mm in size, integrated technology and high-end products. Our led modules highly integrate the main components of the led display in one panel, making it possible to complete the display in a small size. It enables it to be assembled into a variety of abnormal sizes and can be used as different angle corner display.
Features:
1- COMPACT PANEL
It can work as an individual panel with 250x500mm size.
2- MAGNETIC MODULE
Pure front service led module with magnets. Accurate assembling of corresponding hole position
3- HIGHLY INTEGRATED
Each led panel has its own power supply and receiving card and transmits power and signal synchronously.
4- MULTI-MODULE INSTALLATION
45°edges of the modules can build 90°straight corner, inner or outer curved video wall.
5- PURE OUTDOOR
Protection rating up to IP67, flawless use under outdoor condition.
Technical Parameters:
| Parameter | Description |
|---|---|
| Display Type | LED |
| Viewing Angle | 140°/140° |
| Power Consumption | 600W/㎡ |
| Input Voltage | AC220V/50Hz |
| Operating Temperature | -20°C~50°C |
| IP Rating | IP67 |
| Control System | Synchronization/ Asynchronization |
| Module Size | 250mm*500mm |
| Brightness | 4000cd/m2 |
| Module Resolution | 64*128 |
Applications:
The Outdoor LED Display Module from VW is the perfect choice for outdoor advertising applications. The Smart Block Plus is designed to provide a high quality image in a wide range of outdoor settings. It is equipped with a CE and ROHS certification, and is available at a minimum order quantity of 1pcs, with a negotiable price. It is packed in a plywood box and will be delivered within 15 days, with payment terms of T/T. An impressive supply ability of 1500sqm/month is ensured, with an unbeatable IP rating of IP67. The module supports Synchronization/ Asynchronization control systems, is 250mm*500mm in size, and offers 64*128 module resolution. It is powered by AC220V/50Hz input voltage.
Customization:
- Brand Name: VW
- Model Number: Smart Block Plus
- Place of Origin: CN
- Certification: CE, ROHS
- Minimum Order Quantity: 1pcs
- Price: Negotiable
- Packaging Details: Plywood box
- Delivery Time: 15 days
- Payment Terms: T/T
- Supply Ability: 1500sqm/month
- Module Resolution: 64*128
- Operating Temperature: -20°C~50°C
- Viewing Angle: 140°/140°
- Power Consumption: 600W/㎡
- Operating Humidity: 10%~90%
Our VW Smart Block Plus Outdoor LED Display Module is an excellent choice for your outdoor display needs. It is CE and ROHS certified and can be customized to your needs. It comes with a minimum order quantity of 1pcs and comes with a plywood box. It has a delivery time of 15 days and payment terms of T/T. The supply ability is 1500sqm/month and the module resolution is 64*128. It has an operating temperature range of -20°C~50°C and a viewing angle of 140°/140°. Its power consumption is 600W/㎡ and its operating humidity is 10%~90%.
Support and Services:
We provide technical support and service for Outdoor LED Display Module. Our support includes:
- Help with installation, setup, and troubleshooting
- Software updates
- Repair and replacement services
- Extended warranties
- Expert technical advice
Packing and Shipping:
Outdoor LED Display Module Packaging and Shipping:
Our Outdoor LED Display Module is securely packaged to ensure it arrives in perfect condition. We use high-quality protective materials such as bubble wrap, foam, and cardboard to protect the Module. The Module is then placed in a sealed box for shipping.
We also offer express shipping services to ensure that the Module arrives quickly and safely. We use reliable shipping services such as FedEx, UPS, and DHL to ensure the Module arrives on time and in perfect condition.
FAQ:
Q1. Do you have certifications?
A:Yes, we do have CE, ROHS, LVD, ETL, FCC certificates for this product.
Q2. What sizes can you make for this panel?
A:It can make 500mm, 750mm, 1000mm, 1250mm with aluminum frames.
Q3. Which led system is it?
A:This product is compatible with NovaStar control system.
Q4. Can it do rear service?
A:It is front service with our own design aluminum frame.
Q5. How do you pack up the modules?
A:We use anti-static bags, foam and carton box to pack up the modules one by one, then load them up in the plywood case to protect the led.
