P1.25 Smart Poster Led Screen COB 500*1000mm Cabinet 5×5 For Presentation
Product Details:
| Place of Origin: | China |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P1.25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | 3-6 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000sqm per month |
|
Detail Information |
|||
| Product Name: | P1.25 Smart Poster Led Screen COB 500*1000mm Cabinet 5×5 For Presentation | Pixel Pitch: | 1.25mm |
|---|---|---|---|
| Cabinet Size: | 600*337.5 | Display Size: | 3000*1687.5mm |
| IP Rating: | Front:IP65/Rear:lP30 | Maintenance: | Front Service |
| Display Weight: | 180KG (floor Standing) 130KG(wall-mounted) | Installation Type: | Standing/Mounting/Hanging |
| Highlight: | P1.25 COB LED poster screen,500x1000mm smart LED display,5x5 cabinet LED presentation screen |
||
Product Description
P1.25 Smart Poster LED Screen COB 500*1000mm Cabinet 5×5 For Presentation
Product Overview
The P1.25 Smart Poster LED Screen (16:9 Ratio COB) is a cutting-edge display solution designed for versatile applications including exhibitions, advertising, and conferences. Featuring an ultra-fine 1.25mm pixel pitch and an expansive 136-inch screen, it produces exceptionally sharp and vibrant visuals that stand out in any setting.
Key Features
- Ultra-thin: Easy installation - works like a large TV
- Adjustable height: Suitable for various installation scenarios
- Wireless screen sharing: Compatible with Windows, Mac OS, iOS, and Android systems
- File management: Supports file organization, playback, and selective deletion with file categorization (pictures, music, videos)
Technical Specifications
| Model | CrystalTV 136" (5×5) |
|---|---|
| Pixel Pitch | 0.7mm | 0.9mm | 1.25mm | 1.56mm |
| Cabinet Dimension | 600*337.5mm |
| Module Size | 150×168.75mm |
| LED Type | COB |
| Display Size | 3000*1687.5mm |
| Display Resolution | 3840*2160 | 3200*1800 | 2400*1350 | 1920*1080 |
| Display Weight | 180KG (floor standing) 130KG (wall-mounted) |
| Driving Type | 1/36 | 1/36 or 1/54 | 1/27 or 1/60 | 1/48 |
| Maintenance | Front service |
| Brightness | 600/2000nits | 600/2000nits | 600/1500nits | 600/1000nits |
| Max/Avg Power | 196/65W/m² | 280/95W/m² | 330/110W/m² | 330/100W/m² |
| IP Rating | Front:IP65/Rear:lP30 |
| Refresh Rate | >3840Hz |
| Installation Type | Standing/Mounting/Hanging |
| Gray Scale | 16bit |
| Viewing Angle | H: 170° V:170° |
| Operational Temp | -20℃~+50℃ |
| Operational Humidity | 10%~90%RH |
Applications
- Conference rooms
- Lecture theaters
- Multimedia rooms
- Educational establishments
- Telemedicine facilities
Support & Service
Pre-Sale Service
- 24-hour response to inquiries
- Market research, forecasts, and tailored solutions
- Datasheets, samples, custom packaging design, and factory visits available
In-Sale Service
- Production monitoring with photo/video updates
- Complimentary spare parts included
After-Sale Service
- 24-hour complaint response with 48-hour resolution
- 24-month warranty coverage
- Free technician training and comprehensive documentation provided
Frequently Asked Questions
Q1: Do you accept sample orders?
A1: Yes, we welcome sample orders for quality testing. You can choose any item you're interested in.
Q2: Is there a warranty on your products?
A2: Yes, a two-year warranty for all products.
Q3: How is the shipping cost calculated?
A3: Shipping costs are determined by the total weight of your order. We choose the most economical and dependable shipping option based on your order size and delivery location.
Q4: How does your factory maintain quality control?
A4: Always a pre-production sample before mass production; Always final Inspection before shipment.
Q5: Can I customize the product with my logo?
A5: Yes, we offer logo customization. Please share your logo design and our team will confirm the details before production.
Q6: What information do I need to provide to order a display?
A6: Please provide the display width/height, primary use, viewing distance, scene photos, and any special requirements. We will then provide a detailed quotation.
