P1.25 COB Small Pixel Pitch LED Display Better Heat Dissipation Longer Lifetime
P1.25 COB Small Pixel Pitch LED Display Better Heat Dissipation Longer Lifetime
Brand Name
Visual World
Product Model
P1.25
Certificate
EMC,CE,FCC,ROHS
Country Of Origin
CN
MOQ
Negotiate
Unit Price
Negotiate
Payment Method
T/T
Supply Capacity
5000 sqm/month
Product Details
Highlight:
P1.25 COB LED display
,small pixel pitch LED screen
,heat dissipation LED display
Product Name:
P1.25 COB Small Pixel Pitch LED Display Better Heat Dissipation Longer Lifetime
Pixel Pitch:
1.25mm
Refresh Rate:
>3840Hz Or >7680Hz
Cabinet Size:
600×337.5×29.5mm
Maintenance:
Front Service
IP Rating:
Front: IP54 Rear: IP30
Cabinet Weight:
4kg
Installation Type:
Mounting/Hanging/Stacking
Product Description
Detailed Specifications And Features
P1.25 COB Small Pixel Pitch LED Display - Better Heat Dissipation & Longer Lifetime
Product Overview
The P1.25 COB Small Pixel Pitch LED Display leverages advanced full flip-chip COB technology to deliver a slim, lightweight, and ultra-thin structure. Its 16:9 aspect ratio ensures effortless compatibility with varied content formats, while front-access maintenance streamlines servicing. An optimized thermal management system extends product longevity, and integrated signal and power redundancy ensures continuous operation—establishing it as the ideal choice for high-performance display applications.
Key Features
- Full flip-chip COB process with advanced protective technologies including anti-collision, waterproofing, moisture resistance, and salt-spray protection
- 3D ink printing technology enhances contrast by 20% while reducing brightness requirements
- Built-in LCD status display panel for real-time operational monitoring
- HDI multi-layer PCB design ensures uniform color representation and stable temperature management
- Energy-efficient common cathode chips deliver exceptional 16-bit grayscale performance
Technical Specifications
| Model | P0.7 | P0.9 | P1.25 | P1.56 |
|---|---|---|---|---|
| Pixel Pitch | 0.78mm | 0.9375mm | 1.25mm | 1.56mm |
| LED Type | Flip-COB (common cathode) | |||
| Cabinet Dimension (mm) | 600*337.5*29.5 | |||
| Cabinet Resolution | 768*432 | 640*360 | 480*270 | 384*216 |
| Module Size (mm) | 150x168.75 | |||
| Cabinet Weight | 4kg | |||
| Cabinet Material | Die-casting Aluminum | |||
| Driving Type | 1/36 | 1/36 or 1/54 | 1/27 or 1/60 | 1/48 |
| Maintenance | Front service | |||
| Brightness | 600/2000 nits | 600/2000 nits | 600/1500 nits | 600/1000 nits |
| Max Power | 390W/m² | 420W/m² | 330W/m² | 330W/m² |
| Avg Power | 136W/m² | 147W/m² | 100W/m² | 100W/m² |
| IP Rating | Front: IP54 Rear: IP30 | |||
| Refresh Rate | >3840Hz or >7680Hz | |||
| Installation Type | Mounting/Hanging/Stacking | |||
| Gray Scale | 16bit | |||
| Viewing Angle | H:170° V:170° | |||
| Operational Temp | -20℃~+50℃ | |||
| Operational Humidity | 10%-90%RH | |||
Applications
- Digital Signage Systems: Ideal for malls, airports, stations, and offices with vibrant, high-brightness displays for dynamic content
- Football Stadiums: Delivers high-resolution replays and scores with reliable performance and efficient heat dissipation
- Perimeter LED Posters: Perfect for sports fields and event venues with easy installation and maintenance
- Arena Displays: Designed for concert halls and convention centers with vivid visuals and high contrast
Service & Support
- Pre-Sale Services: 24-hour response, market research, customized solutions, datasheets, samples, and factory visits
- In-Sale Process: Production monitoring, photos/videos upon request, free spare parts included
- After-Sales Support: 24-hour complaint response, maintenance guidance within 48 hours, 24-month warranty, free technician training
Frequently Asked Questions
Q1: Do you offer sample orders?
A1: Yes, we welcome sample orders so you can assess the quality and test the market before committing to bulk purchases.
Q2: Is there a warranty included?
A2: Definitely! We provide a 24-month warranty on our products to guarantee your satisfaction and confidence in our offerings.
Q3: Can I customize the product?
A3: Of course! We provide full customization options, supported by our dedicated product development team to meet your specific requirements.
Q4: What is your minimum order quantity (MOQ)?
A4: There is no strict MOQ, and we offer competitive pricing for bulk orders.
Q5: Does it support HD video playback?
A5: Yes, it delivers high-definition video playback when used with Novastar or Colorlight control systems.
