P0.9375 Small Pixel Pitch LED Display 16:9 Golden Ratio For Home Video Display

P0.9375 Small Pixel Pitch LED Display 16:9 Golden Ratio For Home Video Display
Brand Name
Visual World
Product Model
FP0.9375
Certificate
EMC,CE,FCC,ROHS
Country Of Origin
CN
MOQ
Negotiate
Unit Price
Negotiate
Payment Method
T/T
Supply Capacity
5000 sqm/month
Product Details
Highlight:

P0.9375 fine pixel pitch LED display

,

small pixel pitch LED display for home

,

16:9 golden ratio LED video display
Product Name: P0.9375 Small Pixel Pitch LED Display 16:9 Golden Ratio For Home Video Display
Pixel Pitch: 0.9375mm
Cabinet Material: Die-casting Aliuminum
Cabinet Size: 600×337.5×58 Mm
Maintenance: Front Service
Brightness: 400nits
Cabinet Weight:: 5.5kg
IP Rating: F: IP30, R: IP45
Product Description
Detailed Specifications And Features
P0.9375 Small Pixel Pitch LED Display 16:9 Golden Ratio For Home Video Display
The P0.9375 Small Pixel Pitch LED Display delivers outstanding visual performance with ultra-detailed imagery and vibrant color reproduction. Its optimized 16:9 aspect ratio ensures broad viewing angles and comfortable immersion for all audiences. The integrated control system simplifies operation, while the full front-access maintenance design enables effortless servicing--keeping the display at peak performance with minimal downtime.
P0.9375 Small Pixel Pitch LED Display 16:9 Golden Ratio For Home Video Display 0
Key Features
  • Full flip-chip COB process includes protection technologies such as anti-collision, waterproofing, moisture resistance, and salt spray resistance
  • 3D ink printing technology enhances contrast by 20% and lowers display brightness requirements
  • HDI multi-layer circuit board design ensures good color uniformity and even temperature distribution
  • Energy-efficient common cathode chip delivers higher performance with grayscale levels up to 16-bit
  • LCD status display panel for intuitive real-time monitoring of cabinet operations
Technical Specifications
Product Model FP0.9 FP1.25 FP1.56 FP1.87
Pixel Pitch 0.9375mm 1.25mm 1.5625mm 1.875mm
LED Type 4 in 1 LED SMD1212 SMD1212 SMD1515
Cabinet Dimension 600x337.5x58 mm 600x337.5x58mm 600x337.5x58mm 600x337.5x58mm
Module Size 300x168.75 mm 300x168.75 mm 300x168.75 mm 300x168.75 mm
Cabinet Weight 5.5 kg 5.5 kg 5.5 kg 5.5 kg
Cabinet Material Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum
Brightness 400 nits 600 nits 600 nits 600 nits
Max/Avg Power 450/135 W/m² 450/135 W/m² 450/135 W/m² 450/135 W/m²
IP Rating F: IP30, R: IP45 F: IP30, R: IP45 F: IP30, R: IP45 F: IP30, R: IP45
Refresh Rate >3840 Hz >3840 Hz >3840 Hz >3840 Hz
Gray Scale 14 bit 14 bit 14 bit 14 bit
Viewing Angle H:140°; V:140° H:140°; V:140° H:140°; V:140° H:140°; V:140°
Operational Temp -20℃~+50℃ -20℃~+50℃ -20℃~+50℃ -20℃~+50℃
Typical Applications
  • Digital Signage system
  • Chain store displays
  • Billboards
  • Perimeter LED posters
  • Arena displays
P0.9375 Small Pixel Pitch LED Display 16:9 Golden Ratio For Home Video Display 1 P0.9375 Small Pixel Pitch LED Display 16:9 Golden Ratio For Home Video Display 2
Support and Service

Pre-sales: Detailed production instructions and professional installation guidance.

Sales: Customized solutions, visual designs, and project showcases.

After-sales: Two-year warranty, professional maintenance team, timely assistance, spare parts provision, free training, logistics tracking, and continuous software improvement.

Frequently Asked Questions
Q1: Can you accept some sample orders?
A1: Yes, the sample order is acceptable for quality check and market test.
Q2: What LED screen size you can do?
A2: Screen size can be customized based on your demand.
Q3: Does there have any warranty?
A3: A two-year warranty for all products.
Q4: How to guarantee product quality?
A4: We prioritize quality at every stage of production. Our rigorous quality control processes include stringent component selection, advanced manufacturing techniques, and comprehensive testing. Before shipment, each LED floor display undergoes a meticulous final inspection to ensure it meets our exacting standards.
Q5: How fast can you provide after-sale technical support after encountering product problems?
A5: We promise to provide professional after-sale technical support within 24 hours after receiving the customer's notice.
