P3.9 Holographic Transparent LED Film Display 70% Transparent 6kg/sqm Aluminum+PCB
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P3.9 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case, flight case |
| Delivery Time: | 5-10 days |
| Payment Terms: | T/T,L/C,D/A,D/P |
| Supply Ability: | 3000sqm/month |
|
Detail Information |
|||
| Product Name: | P3.9 Holographic Transparent LED Film Display 70% Transparent 6kg/sqm Aluminum+PCB | Brightness: | 1000-5000nits |
|---|---|---|---|
| Waterproof: | IP42 | Led Type: | SMD1415 1R1PG1PB UV |
| Driving Method: | Static | Transparent Rate: | 70% |
| Maintenance: | Rear Service | Cabinet Size: | 600/1200/1800x500/600/700/800mm |
| Cabinet Material: | Aluminum+PCB | Panel Weight: | 6 Kg/sqm |
| Highlight: | P3.9 transparent LED display,holographic LED film display,aluminum PCB LED screen |
||
Product Description
P3.9 Holographic Transparent LED Film Display 70% Transparent 6kg/sqm Aluminum+PCB
Product Description
P3.9 Indoor Holographic Transparent LED Display is an innovative display solution designed for indoor applications that require a high level of visual engagement without compromising on aesthetics or space. This lightweight display system, weighing only 6kg per square meter, offers a perfect blend of technology and design.
Features
- Transparent: Industry premiere, with no structural backbone; Real fully transparent; Permeability can reach 70%
- Thin: Module thickness <3mm; Seamless curved surface mounting integrated seamlessly onto glass
- Foldable and arbitrary transformation shape; Soft and bendable. It can be customized into different shapes according to different scenes, for example, triangles, ellipses, etc.
Technical Parameters
| Parameter | Specification |
|---|---|
| Pixel Pitch (H/V) | W:3.9; H:3.9mm |
| LED Configuration | SMD1415 1R1PG1PB UV |
| Pixel Density | 65536dot/㎡ |
| Transparency | <66.66% |
| Drive Scheme | 18 aisle |
| Scan method | 0 Scan(6 layer PCB) |
| Refresh Rate | 1920-3840Hz |
| Module Size | 375/750/1125/1500X125mm(L/R) |
| Module Resolution | 96/192/288/384X32dot |
| Product Size | 375/750/1125/1500X500mm |
| Cabinet Resolution | 96/192/288/384X128dot |
| Cabinet Weight | 6kg/㎡ |
| IP Rating (front/back) | IP42 |
| Brightness | 1000-5000nits/㎡ |
| Viewing Angle (H/V) | 140°/140° |
| Viewing Distance | 4m |
| Gray Scale | 16 bit |
| Max. Power Consumption | 800W/m² |
| Ave. Power Consumption | 240W/m² |
| Maintenance | Rear service |
| Environment | indoor |
Applications
- Retail Displays: Enhance product showcases with dynamic holographic displays that capture the attention of shoppers and provide an immersive shopping experience.
- Galleries and Exhibitions: Provide a unique viewing experience for art and exhibits, allowing visitors to see the artwork in a new light.
- Corporate Settings: Use in conference rooms and lobbies for impactful presentations and informational displays that leave a lasting impression.
- Entertainment Venues: Create immersive environments in theaters, clubs, and other entertainment spaces, adding depth and excitement to the atmosphere.
Frequently Asked Questions
Q1: LED display models are generally expressed in PX, such as P2 P3 P4.....P8, P10, what does this mean?
A1: P3 P4.....P8,P10 means that the pixel pitch is 3mm 4mm....10mm, which determines resolution of a display. Pixel pitch is smaller, led display resolution is higher.
Q2: What pixel pitch should I choose on my display?
A2: It is determined mainly by the viewing distance, the size of the display screen, the desired effect and the customer budget.
Q3: To order a display, what kind of information do I have to offer you?
A3: You should provide width/height of the display, the main use, the viewing distance, the scene photos, special requirements, then I can provide you with a detailed list of quotations.
Q4: How to install?
A4: Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram, free remote debugging. We can also send our engineers to the site to guide the installation if needed.
Q5: Can I order a sample?
A5: Yes, We welcome customers to order samples to check our product quality of our products and service.
