P1.875 Fine Pixel Pitch Outdoor LED Display SMD1415 For Commercial Advertising
Product Details:
| Place of Origin: | CN |
| Brand Name: | Visual World |
| Certification: | CE,FCC,ROHS |
| Model Number: | P1.875 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | 12 work days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 sqm/month |
|
Detail Information |
|||
| Product Name: | P1.875 Fine Pixel Pitch Outdoor LED Display SMD1415 For Commercial Advertising | Pixel Pitch: | 1.875mm |
|---|---|---|---|
| Cabinet Material: | Aluminum Alloy | Module Size: | 300x337.5mm |
| Cabinet Size: | 600x337.5×50mm | Brightness: | 4500nits |
| Operating Environment: | Outdoor Use | LED Type: | SMD1415 |
| Highlight: | P1.875 outdoor LED display,SMD1415 commercial LED screen,fine pixel pitch advertising display |
||
Product Description
P1.875 Fine Pixel Pitch Outdoor LED Display SMD1415 For Commercial Advertising
Product Description
Introducing our advanced Small Pixel Pitch Display -- engineered to redefine visual experiences with exceptional performance, energy efficiency, and seamless ultra-HD clarity. Designed for high-impact applications, it excels in premium digital signage, control room monitoring, and immersive VR/XR simulations.
Features
- The independent module design is easy to install and remove.
- No need to reserve maintenance access for outdoor installation.
- OFP adopts a die-casting cabinet, which not only ensures the stability of the product structure, but also ensures its excellent heat dissipation performance, preventing the internal components from overheating, thus prolonging the service life of the LED display and keeping it in the best working condition.
- OFP supports front service installation and is designed to reduce its reliance on human resources while controlling overall costs.
- The refresh rate is as high as 3840Hz or more, dynamically eliminating screen tearing and shadow dragging; precise synchronization of high-speed shutter shooting, live events and other high-speed sports scenes show no shadow residual image.
Technical Parameters
| Pixel Pitch(mm) | 1.875 |
|---|---|
| Module Size(mm) | 150 x 337.5 |
| Module Resolution(dot) | 80 x 180 |
| Module Assembly | 4 x 1 |
| Panel Size(w x h x d)(mm) | 600 x 337.5 x 50 |
| Panel Resolution(dot) | 320 x 180 |
| LED Type | SMD1415 |
| Brightness(cd/m2) | 4500 |
| Horizontal Viewing Angle | 140° |
| Vertical Viewing Angle | 140° |
| Gray Level | 16384 |
| Refresh Rate(Hz) | 3840Hz |
| Max. AC power consumption | 700W/m2 |
| Avg. AC power consumption | 350W/㎡ |
| Voltage | AC100~240 50/60HZ |
| Operate Temp(℃) | -30℃~+50℃ |
| Storage Temp(℃) | -40～80 ℃ |
| Operating Humidity | 10~95% RH |
| Protection grade | IP65 |
| Operating Environment | Outdoor |
| Cabinet Material | Aluminum alloy |
| LED Lifetime(H) | 100,000 |
| Weight(kg/pc) | 6 |
Applications
- Digital Signage system
- Chain store
- Street furniture
- Billboard
- Football stadium
- Perimeter LED poster
- Arena display, etc.
Packing and Shipping
Packing: Anti-shaking wooden cabinet/Air flight case/strong carton
Shipping port: Shenzhen, China
Shipping way: Air;Express;Ocean;Land Transportation
Delivery time: 10-15 working days after confirm receipt payment in advance.
FAQ
Q1: Can you provide customized services?
A1: Yes, we can design different categories of products according to your demand.
Q2: Is it OK to print our logo on the LED screen product?
A2: Yes, we can print your logo according to your request.
Q3: Can I order a sample for the LED display screen?
A3: Yes, we welcome you to order a sample to test and check quality. You can choose any item that you want.
Q4: How much is the freight?
A4: The shipping cost is determined by the size of the screen, and the project information is informed by the inquiry.
Q5: Do you offer a guarantee for the products?
A5: Yes, we offer 2 years warranty on our products.
