P2.8 Full Color Window Screen Cabinet 1000x500mm Aluminum For Indoor Use
Product Details:
| Place of Origin: | CN |
| Brand Name: | VW |
| Certification: | CE, ROHS |
| Model Number: | TF2.8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, carton box |
| Delivery Time: | 15 days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm/month |
|
Detail Information |
|||
| Product Name: | P2.8 Full Color Window Screen Cabinet 1000x500mm Aluminum For Indoor Use | Pixel Pitch: | 2.8*5.6 Mm |
|---|---|---|---|
| Module Size: | 500×125mm | Cabinet Size: | 1000×500×84mm |
| LED Type: | SMD2121; SMD1921 | Brightness:: | 800-5500 Nits |
| IP Rating: | F: IP20, R: IP21 | Installation Type:: | Mounting/Hanging |
| Highlight: | P2.8 indoor LED display,aluminum cabinet LED screen,1000x500mm transparent LED display |
||
Product Description
| Attribute | Value |
|---|---|
| Product Name | P2.8 Full Color Window Screen Cabinet 1000x500mm Aluminum For Indoor Use |
| Pixel Pitch | 2.8*5.6 mm |
| Module Size | 500×125mm |
| Cabinet Size | 1000×500×84mm |
| LED Type | SMD2121; SMD1921 |
| Brightness | 800-5500 nits |
| IP Rating | F: IP20, R: IP21 |
| Installation Type | Mounting/Hanging |
The seamless fusion of LED technology and transparent glass achieves a uniquely sophisticated visual harmony, uniting innovation with architectural elegance. This solution effortlessly adapts to curved surfaces, frameless installations, and fully bespoke designs—every element showcasing meticulous craftsmanship and customized professional support to fulfill precise client needs.
- Brightness 800-5500nits adjustable
- Quick Installation and Maintenance
- Fast lock mechanism
- Frontal protection
| Specification | Value |
|---|---|
| Product Model | TF2.8 |
| Pixel Pitch | 2.8*5.6 mm |
| LED Type | SMD2121; SMD1921 |
| Cabinet Dimension | 1000x500x84 mm |
| Module Size | 500x125 mm |
| Cabinet Weight | 3.5 kg |
| Cabinet Material | Aluminum |
| Driving Type | 1/11 |
| Brightness | 800-5500 nits |
| Max/Avg Power | 400/140; 800/280 W/m² |
| Transparency Rate | 45% |
| Environment | Indoor Use |
| IP Rating | F:IP20, R: IP21 |
| Refresh Rate | >1920 Hz |
| Installation Type | Mounting/Hanging |
| Gray scale | 14 bit |
| Viewing Angle | H:140°: V:140 |
| Operational Temp | -20°C~+60℃ |
| Operational Humidity | 10%~90% RH |
Supermarket, airport advertising display, self-service store, metro station, museum, convenience store, stadium exhibition, chain brand store, high-end conference room, luxury brand store, hotel, bar, theatre, cinema, T stage, showroom, tourist attractions...
A1: Yes, we welcome sample orders to test and check quality. Both for module or whole screen.
A2: Order less than 100 square meter lead time takes 15 working days.
A3: Low MOQ, 1 square meter or a module checking is available.
A4: We mostly accept FOB train term, but we can help you order and arrange shipping agent. It usually takes 20-30 days by sea, plus a few days for customer clearance.
A5:
1. Let us know your requirements or application.
2. We quote according to your requirements or our suggestions.
3. Customer confirms the design document and places deposit for formal order.
4. We arrange the production.
A6: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
A7: Yes, we offer 1 year warranty for our products.
A8:
1. Our products are produced with strict quality control and the defective rate will be less than 0.2%.
2. During the guarantee period, we will send new modules with new order for small quantity.
3. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
