P1.56 Smart LED Poster Display COB 108" 2400*1350mm Die-casting Aluminum 16:9 Ratio
Product Details:
| Place of Origin: | China |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P1.56 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | 3-6 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000sqm per month |
|
Detail Information |
|||
| Product Name: | P1.56 Smart LED Poster Display COB 108" 2400*1350mm Die-casting Aluminum 16:9 Ratio | Pixel Pitch: | 0.7mm,0.9mm,1.25mm,1.56mm |
|---|---|---|---|
| Display Size: | 2400*1350mm | LED Type: | COB |
| Cabinet Dimension: | 600*337.5 | Cabinet Material: | Die-casting Aluminum |
| Maintenance: | Front Service | Display Ratio: | 16:9 |
| Highlight: | P1.56 Smart LED Poster Display,108" COB LED Display,Die-casting Aluminum LED Poster |
||
Product Description
P1.56 Smart LED Poster Display COB 108" 2400*1350mm Die-casting Aluminum 16:9 Ratio
Product Attributes
| Attribute | Value |
|---|---|
| Product Name | P1.56 Smart LED Poster Display COB 108" 2400*1350mm Die-casting Aluminum 16:9 Ratio |
| Pixel Pitch | 0.7mm,0.9mm,1.25mm,1.56mm |
| Display Size | 2400*1350mm |
| LED Type | COB |
| Cabinet Dimension | 600*337.5 |
| Cabinet Material | Die-casting Aluminum |
| Maintenance | Front Service |
| Display Ratio | 16:9 |
Product Description
The P1.56 Smart LED Poster Display is an advanced display solution designed for conferences, exhibitions, and advertising. With an ultra-fine 1.56mm pixel pitch and a 108-inch screen, it delivers crisp visuals and rich colors, making it a striking focal point in any setting.
Key Features
- Sleek & Lightweight Design: No complex installation required—operates just like a large TV.
- Height Adjustable: Adaptable for various environments and usage scenarios.
- Seamless Wireless Screen Sharing: Compatible with Windows, Mac OS, iOS, and Android for effortless screen mirroring.
- Efficient File Management: Supports file playback and organization, with options for selective or bulk deletion, categorizing files into images, music, videos, and more.
Technical Specifications
| Model | CrystalTV 108" (4X4) | |||
|---|---|---|---|---|
| Pixel Pitch | 0.7mm | 0.9mm | 1.25mm | 1.56mm |
| Cabinet Dimension (mm) | 600*337.5 | 600*337.5 | 600*337.5 | 600*337.5 |
| Module Size(mm) | 150x168.75 | 150x168.75 | 150x168.75 | 150x168.75 |
| LED Type | COB | COB | COB | COB |
| Display Size(mm) | 2400*1350 | 2400*1350 | 2400*1350 | 2400*1350 |
| Display Resolution | 3072*1728 | 2560*1440 | 1920*1080 | 1536*864 |
| Display Ratio | 16:9 | 16:9 | 16:9 | 16:9 |
| Cabinet Weight | 130KG (floor standing) 100KG (wall-mounted) | 130KG (floor standing) 100KG (wall-mounted) | 130KG (floor standing) 100KG (wall-mounted) | 130KG (floor standing) 100KG (wall-mounted) |
| Cabinet Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Driving Type | 1/36 | 1/40 | 1/60 | 1/48 |
| Maintenance | Front service | Front service | Front service | Front service |
| Brightness | 0-2000 nits | 0-800 nits | 0-800 nits | 1000 nits |
| Max Power Avg Power | 196W/m² 65W/m² | 280W/m² 95W/m² | 330W/m² 110W/m² | 330W/m² 100W/m² |
| IP Rating | Front: IP65 Rear: IP30 | Front: IP65 Rear: IP30 | Front: IP65 Rear: IP30 | Front: IP65 Rear: IP30 |
| Refresh Rate | >3840Hz | >3840Hz | >3840Hz | >3840Hz |
| Installation Type | Floor Standing Wall Mounting Hanging | Floor Standing Wall Mounting Hanging | Floor Standing Wall Mounting Hanging | Floor Standing Wall Mounting Hanging |
| Gray Scale | 16bit | 16bit | 16bit | 16bit |
| Viewing Angle | H:170°V:170° | H:170°V:170° | H:170°V:170° | H:170°V:170° |
| Operational Temp | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
| Operational Humidity | 10%-90%RH | 10%-90%RH | 10%-90%RH | 10%-90%RH |
Applications
- Conference room
- Lecture theater
- Multimedia room
- Educational establishment
- Telemedicine
Frequently Asked Questions
Q1: Are you the manufacturer or trading company? and where is your factory?
A1: We are professional manufacturer devoted to producing LED outdoor, LED indoor display, rental display, stadium screen, advertising screen and stage screen etc. You are warmly welcome to visit our factory to learn the technical and maintenance skills and everything you need in our factory.
Q2: May be we will need some samples, what is the lead time of samples and lead time of order?
A2: We will arrange your sample of the charges within 1-2 days and arrange your order within 5-12 days after receiving your payment.
Q3: How can I place an order?
A3: Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Whatsapp/Wechat/Skype/Email/Phone, in case of any delays.
Q4: How about the quality?
A4: Our LED products must be testing of at least 72 hours before shipping, from purchase raw materials to ship. Each step has strict quality control systems to ensure LED display with good quality.
Q5: Can you offer a technical support? Since it's my first time....
A5: We provide free training for our customer, teach the customer how to set up screens, make configuration of parameters, broadcast the videos through Nova star and colorlight or Linsn control systems, our engineer can directly teach you how to control, or help you to do if you really don't know how to control (Our Engineer can text English, we can saving more time).
