P4 Outdoor LED Display Module 320x320mm Die-casting Aluminum 5000nits IP67
Product Details:
| Place of Origin: | China |
| Brand Name: | VW |
| Certification: | EMC,CE,FCC,ROHS |
| Model Number: | P4 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiate |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Plywood case, export carton box |
| Delivery Time: | 3-6 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000sqm per month |
|
Detail Information |
|||
| Product Name: | P4 Outdoor LED Display Module 320x320mm Die-casting Aluminum 5000nits IP67 | Pixel Pitch: | 2.85mm,4mm, 6.67mm |
|---|---|---|---|
| IP Level:: | IP67 | Module Size: | 320x320x37mm |
| Maintenance: | Front Service | Cabinet Material: | Die-casting Aluminum |
| Cabinet Weight: | 15kg/sqm | Brightness: | 5000nits |
| Highlight: | P4 LED Display Module,IP67 LED Display Module,P4 Outdoor LED Display Module |
||
Product Description
P4 Outdoor LED Display Module 320x320mm Die-casting Aluminum 5000nits IP67
Product Description:
The 320x320mm Smart LED Module boasts a modular design, offering flexible and scalable display solutions. Its lightweight construction and high protection level ensure easy rigging and long-lasting durability. With an IP67 protection rating, the module is fully waterproof and anti-salt, making it perfect for challenging environments. Designed for user convenience, it allows for effortless assembly, installation, and maintenance. Additionally, its integrated signal and power cabling streamline setup, delivering a seamless and efficient user experience.
Technical Parameters:
| Product Model: | P4 |
| Pixel Pitch: | 4 mm |
| LED Type: | SMD1921 |
| Cabinet Dimension: | 320×320x37 mm |
| Module Size: | 320x320 mm |
| Cabinet Weight: | 15 kg |
| Cabinet Material: | Aluminum |
| Driving Type: | 1/16 |
| Brightness: | >5000 nits |
| Max/Avg Power: | 800/200 W/m2 |
| Maintenance: | Front service |
| Environment: | Outdoor Use |
| IP Rating: | F: IP67, R: IP67 |
| Refresh Rate: | >3840 Hz |
| Installation Type: | Mounting/Hanging |
| Gray Scale: | 14 bit |
| Viewing Angle: | H:140°；V:160° |
| Operational Temp: | -20℃~+60℃ |
| Operational Humidity: | 10%~90% RH |
Features:
- LIGHTWEIGHT
Die-casting aluminum material, only 15kg/sqm, saving shipping costs.
- INTEGRATED DESIGN
Integrate power supply, receiving card, and module into one cabinet.
- Waterproof IP67
- 45° BEVELEDGE DESIGN
45° Beveledge design, various shapes splicing
Installation Method
Application:
- Shopping Mall:
LED screens can display mall directories, store locations, and ongoing promotions, helping shoppers easily navigate and find their preferred stores or amenities.
- Outlets Storefront:
LED screens can showcase real-time deals, flash sales, and new product arrivals, attracting customers and driving increased foot traffic and sales.
- Arc Video Wall:
The curved, high-definition LED design creates a visually immersive experience, ensuring maximum viewer engagement and attention.
FAQ:
Q1: Can you provide OEM/ODM services?
A1: Sure, we have a mature technical team that can customize products and labels
Q2:ls your company a genuine manufacturer?
A2: We are a factory directly supplying from Shenzhen, Guangdong Province. Welcome to visitour factory.
Q3:How to choose a suitable display screen?
A3: Determine size and resolution based on usage scenarios and requirements, And the quality and stability of the display screen.
Q4: What kind of after-sales service can you provide?
A4: Technical support: Provide technical consultation and guidance to help users solve problemsencountered during use, Remote collaboration: A dedicated after-sales department operatesremotely online to ensure the normal use of the screen.
Q5: ls there a quality check before delivery of the displays?
A5: Absolutely. We conduct a thorough 100% quality test with a 72-hour aging process to ensureeach display unit meets our stringent quality standards before delivery.
Q6: How long is the delivery time for your displays?
A6: The typical delivery time is 15-20 days after receiving the deposit. However, delivery time may vary depending on order quantity and specific requirements.
