P0.9 Small Pitch LED Display COB 600x337.5mm Die-casting Aluminum 3840Hz
P0.9 Small Pitch LED Display COB 600x337.5mm Die-casting Aluminum 3840Hz
Brand Name
Visual World
Product Model
P0.9
Certificate
EMC,CE,FCC,ROHS
Country Of Origin
CN
MOQ
Negotiate
Unit Price
Negotiate
Payment Method
T/T
Supply Capacity
5000 sqm/month
Product Details
Highlight:
COB Small Pitch LED Display
,P0.9 Small Pitch LED Display
Product Name:
P0.9 Small Pitch LED Display COB 600x337.5mm Die-casting Aluminum 3840Hz
Pixel Pitch:
P0.7/P0.9/P1.25/P1.56
Cabinet Material:
Die-casting Aliuminum
Size:
600x337.5mm
Maintenance:
Front/Rear Service
Brightness:
600-800nits
Refresh Rate:
＞3840Hz
Durability:
100000 Hours
Product Description
Detailed Specifications And Features
P0.9 Small Pitch LED Display COB 600x337.5mm Die-casting Aluminum 3840Hz
The P0.9 Small Pixel Pitch LED Display COB from VISUAL WORLD is a state-of-the-art display solution that elevates high-definition visuals. With a pixel pitch of just 0.9mm, it guarantees sharp and detailed images, making it perfect for applications that require exceptional visual precision and clarity.
Designed in a compact 600x337.5mm module size, this COB LED display offers flexibility and straightforward installation. Its die-cast aluminum cabinet not only contributes to a sleek, modern look but also ensures the display's durability and lightweight design.
Key Features
- Full flip-chip COB process with protection technology including anti-collision, waterproof, moisture-proof, and salt spray resistance
- Module utilizes 3D ink printing technology, increasing contrast by 20% and reducing brightness requirements
- Supports LCD status display panel for intuitive real-time monitoring of cabinet operation status
- Module PCB employs HDI multi-layer circuit board design for excellent color uniformity and even temperature distribution
- Complete series features Sunrise's energy-saving common cathode chip with higher performance and grayscale levels up to 16bit
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | P0.9 |
| Pixel Pitch | 0.9mm |
| LED Type | COB |
| Cabinet Dimension | 600×337.5×35mm |
| Module Size | 150×168.75mm |
| Cabinet Weight | 4.6kg |
| Cabinet Material | Die-casting Aluminum |
| Driving Type | 1/36 |
| Maintenance | Front service |
| Brightness | 0-2000 nits |
| Max/Avg Power | 420/147 W/m² |
| IP Rating | Front: IP65 / Rear: IP30 |
| Refresh Rate | >3840Hz |
| Installation Type | Mounting / Hanging / Stacking |
| Gray Scale | 16bit |
| Viewing Angle | H:170°; V:170° |
| Operational Temperature | -20℃ to +50℃ |
| Operational Humidity | 10%-90%RH |
Applications
- Digital Signage systems
- Home cinema and theater installations
- Street furniture integration
- Billboard advertising displays
- Football stadium scoreboards and screens
- Perimeter LED posters
- Arena displays and large venue screens
Frequently Asked Questions
Are you the manufacturer or trading company? And where is your factory?
We are professional manufacturer of LED outdoor, LED indoor display, rental display, stadium screen, stage screen and advertising screen. Our company is located in Shenzhen China, which enjoys the transportation and good reputation among our domestic and overseas customers for more than 10 years.
What kind of package can you choose?
Wooden case or airflight case.
What is LED?
LED is the abbreviation for Light Emitting Diode, which emits visible wavelengths. In the LED display industry, these are used to create vibrant visual displays.
What is a pixel and pixel pitch?
The pixel is the smallest unit of light emitting, consisting of red, green and blue colors, similar to ordinary computer monitors. Pixel pitch refers to the center distance between two adjacent pixels.
What is the LED display module?
The base unit determined by circuit and installation structure that has display functionality and can be easily assembled.
What is 3 in 1? What is its advantages and disadvantages?
The RGB color of LED chips are encapsulated using SMT technology and vertically tied together according to certain spacing. The advantages are simple production and excellent display effect. The disadvantages include difficult spectral color separation and higher cost.
