P0.7 COB Small Pixel Pitch LED Display Front Service 600x337.5mm For Speech
Front Service COB LED Display
,Speech COB LED Display
,P0.7 COB LED Display
P0.7 COB Small Pixel Pitch LED Display Front Service 600x337.5mm For Speech
Product Description:
Introducing our P0.7 COB Small Pixel Pitch Display, engineered to revolutionize visual experiences. This advanced display technology delivers unparalleled performance and efficiency, making it the perfect solution for a wide range of applications, including premium digital signage and immersive virtual reality environments.

Features:
- High Brightness: Brightness up to 1000nits.
- Energy Saving: Energy saving 30%.
- High Reliability: Flip-chip common cathode, better heat dissipation, and more stability.
- Patented Appearance Treatment: No white edge and burrs of the module; light transmittance up to 75% and low temperature.
- High Contrast Ratio: >20000: 1.
- High Consistency: Micro LED flip-chip mixed processing technology & same Bin chips.
- Wide Color Gamut: DCI-P3 wide color gamut.
- Easy Installation: Full front maintenance, multiple disassembly, and assembly of LED modules without white edges.
- Various Applications: Support wall-mounted installation, floor-standing, and hanging installation.

Technical Parameters:
| Model | P0.7 | P0.9 | P1.25 | P1.56 |
| Pixel Pitch | 0.7mm | 0.9mm | 1.25mm | 1.56mm |
| LED Type | COB | COB | COB | COB |
| Cabinet Dimension | 600*337.5*35mm | 600*337.5*35mm | 600*337.5*35mm | 600*337.5*35mm |
| Module Size | 150x168.75 mm | 150x168.75 mm | 150x168.75 mm | 150x168.75 mm |
| Cabinet Weight | 4.6kg | 4.6kg | 4.6kg | 4.6kg |
| Cabinet Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Driving Type: | 1/36 | 1/36 | 1/27 | 1/48 |
| maintenance | Front service | Front service | Front service | Front service |
| Brightness | 0-2000 nits | 0-2000 nits | 1500 nits | 1000 nits |
| Max/Avg Power | 390/136 W/m2 | 420/147 W/m2 | 330/100 W/m2 | 330/100 W/m2 |
| IP Rating |
Front: IP54 Rear: IP30 |
Front: IP54 Rear: IP30 |
Front: IP54 Rear: IP30 |
Front: IP54 Rear: IP30 |
| Refresh Rate | >3840Hz | >3840Hz | >3840Hz | >3840Hz |
| Installation Type |
Mounting Hanging Stacking |
Mounting Hanging Stacking |
Mounting Hanging Stacking |
Mounting Hanging Stacking |
| Gray Scale | 16bit | 16bit | 16bit | 16bit |
| Viewing Angle | H:170°;V:170° | H:170°;V:170° | H:170°;V:170° | H:170;°V:170° |
| Operational Temp | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
| Operational Humidity | 10%-90%RH | 10%-90%RH | 10%-90%RH | 10%-90%RH |
Applications:
- Digital Signage system
- Chain store
- Street furniture
- Billboard
- Football stadium
- Perimeter LED poster
- Arena display, etc.


FAQ:
Q1: Do you provide a warranty for your products?
A1: Yes, we offer a 2-year warranty on all our products.
Q2: Is it possible to print my logo on the product?
A2: Yes, we can print your logo. Please inform us formally before production and confirm the design based on our sample.
Q3: Can I place a sample order for the LED screen?
A3: Yes, we welcome sample orders for testing and quality checks. Mixed samples are also acceptable.
Q4: What is your delivery time?
A4: Generally, delivery takes 7–15 days after receiving your deposit. The specific delivery time depends on the order items and quantities.
Q5: What is the control system, and how does it work?
A5: We use the Nova Taurus Series asynchronous control system, which supports cluster play and management. It also allows control via APP, phone, Wi-Fi, iPad, laptop, PC, and cloud. This makes operation very easy and convenient.
-
