Durable, Lightweight Design COB Screen Load with Flexible Installation Options

Durable, Lightweight Design COB Screen Load with Flexible Installation Options
Brand Name
Visual World
Product Model
P0.7 P0.9 P1.2 P1.5
Certificate
EMC,CE,FCC,ROHS
Country Of Origin
China
MOQ
Negotiatble
Unit Price
Negotiatble
Payment Method
T/T
Supply Capacity
5000 sqm/month
Product Details
Highlight:

Lightweight Design COB Screen

,

Flexible Installation Options COB Screen

,

Durable COB Screen

Product Name: Durable, Lightweight Design COB Screen Load With Flexible Installation Options
Brightness: 0-2000nits
Maintaince: Front Serviece
Cabinet Weight: 4.6kg
Cabinet Material: Die-casting Aliuminum
Pixel Pitch: P0.7 P0.9 P1.25 P1.5
Cabinet Dimension: 600x337.5mm
Warranty Time: 2 Years
Operation Temp: -20°C~+50°C
Operational Humidity: 10%-90%RH
Installation Type: Mounting/Hanging/Stacking
Product Description
Detailed Specifications And Features

Durable, Lightweight Design COB Screen Load with Flexible Installation Options



Product Description:



Introducing our advanced COB Small Pixel Pitch display, engineered to deliver stunning clarity and vivid visuals with remarkable energy efficiency. Designed with low power consumption, this display offers exceptional contrast and high pixel density, making it perfect for high-end applications where every detail is crucial. Enjoy superior performance and reduced energy costs, all in a sleek, powerful display solution.



Product Features:

  • High Brightness and Contrast: The P0.7 and P0.9 models offer adjustable brightness up to 2000 nits, ensuring excellent visibility in diverse lighting conditions. The P1.25 and P1.56 models provide brightness levels of up to 1500 nits and 1000 nits, respectively, for clear and vibrant images.

  • Durable, Lightweight Design: Built with die-casting aluminum cabinets, each module weighs just 4.6 kg, making it easy to install, transport, and maintain.

  • Flexible Installation Options: Versatile installation capabilities, including mounting, hanging, and stacking, allow for seamless integration in various environments and applications.

Technical Parameters:


Model P0.7 P0.9 P1.25 P1.56
Pixel Pitch 0.7mm 0.9mm 1.25mm 1.56mm
LED Type COB COB COB COB
Cabinet Dimensions 600337.535mm 600337.535mm 600337.535mm 600337.535mm
Module Size 150x168.75mm 150x168.75mm 150x168.75mm 150x168.75mm
Cabinet Weight 4.6kg 4.6kg 4.6kg 4.6kg
Cabinet Material Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum
Driving Type 1/36 1/36 1/27 1/48
Maintenance Front service Front service Front service Front service
Brightness 0-2000 nits 0-2000 nits 1500 nits 1000 nits
Max/Avg Power 390/136 W/m² 420/147 W/m² 330/100 W/m² 330/100 W/m²
IP Rating Front: IP65 Rear: IP30 Front: IP65 Rear: IP30 Front: IP65 Rear: IP30 Front: IP65 Rear: IP30
Refresh Rate >3840Hz >3840Hz >3840Hz >3840Hz
Installation Type Mounting, Hanging, Stacking Mounting, Hanging, Stacking Mounting, Hanging, Stacking Mounting, Hanging, Stacking
Gray Scale 16bit 16bit 16bit 16bit
Viewing Angle H:170°, V:170° H:170°, V:170° H:170°, V:170° H:170°, V:170°
Operational Temp -20°C~+50°C -20°C~+50°C -20°C~+50°C -20°C~+50°C
Operational Humidity 10%-90%RH 10%-90%RH 10%-90%RH 10%-90%RH



Our Advantage:



Durable, Lightweight Design COB Screen Load with Flexible Installation Options 0



Durable, Lightweight Design COB Screen Load with Flexible Installation Options 1



Application:



Durable, Lightweight Design COB Screen Load with Flexible Installation Options 2



Durable, Lightweight Design COB Screen Load with Flexible Installation Options 3



Durable, Lightweight Design COB Screen Load with Flexible Installation Options 4



FAQ:
Q1: What control system is used, and how does it work?

A1: We use the Nova Taurus Series asynchronous control system, which supports cluster playback and management. You can easily control it via various devices, including APP, smartphone, Wi-Fi, iPad, laptop, PC, or through cloud control. It's very user-friendly and convenient.

Q2: Can I place a sample order for an LED screen?

A2: Yes, we encourage sample orders for testing and quality evaluation. Mixed samples are also accepted.

Q3: Can I have my logo printed on the product?

A3: Absolutely. Please let us know in advance and confirm the design based on our sample before production begins.

Q4: What is your delivery time?

A4: Typically, delivery takes 7-15 days after the deposit is received. However, the exact time depends on the order size and items.

Q5: What is your warranty policy?

A5: We offer a 2-year warranty. We also provide full support for structure design, installation issues, system troubleshooting, and screen usage.
Our professional after-sales team, along with your dedicated sales engineer, will assist with any questions you may have after your order.
