P0.7 COB Small Pixel Pitch LED Display 600x337.5mm For Commercial Advertising

P0.7 COB Small Pixel Pitch LED Display 600x337.5mm For Commercial Advertising
Brand Name
Visual World
Product Model
P0.7
Certificate
EMC,CE,FCC,ROHS
Country Of Origin
CN
MOQ
Negotiate
Unit Price
Negotiate
Payment Method
T/T
Supply Capacity
5000 sqm/month
Product Details
Highlight:

600x337.5mm COB LED Display

,

P0.7 COB LED Display

,

Commercial Advertising COB LED Display
Product Name: P0.7 COB Small Pixel Pitch LED Display 600x337.5mm For Commercial Advertising
Pixel Pitch: P0.7/P0.9/P1.25/P1.56
Cabinet Material: Die-casting Aliuminum
Cabinet Size: 600x337.5mm
Maintenance: Front/Rear Service
LED Type: COB
Cabinet Weight: 4.6kg
Installation Type: Mounting/Hanging/Stacking
Product Description
Detailed Specifications And Features
P0.7 COB Small Pixel Pitch LED Display 600x337.5mm For Commercial Advertising
Introducing our cutting-edge COB Small Pixel Pitch Display, designed to redefine visual experiences. This innovative display technology boasts superior performance and efficiency, ideal for various applications, from high-end digital signage to immersive virtual reality experiences.
P0.7 COB Small Pixel Pitch LED Display showcasing high-resolution visual quality
Key Features
  • Full flip-chip COB process with comprehensive protection including anti-collision, waterproof, moisture-proof, and salt spray resistance
  • 3D ink printing technology increases contrast by 20% and reduces brightness requirements
  • LCD status display panel for real-time monitoring of cabinet operation status
  • HDI multi-layer circuit board design ensures excellent color uniformity and even temperature distribution
  • Sunrise energy-saving common cathode chip technology with 16-bit grayscale level for superior performance
Technical Specifications
Parameter P0.7 P0.9 P1.25 P1.56
Pixel Pitch 0.7mm 0.9mm 1.25mm 1.56mm
LED Type COB COB COB COB
Cabinet Dimension 600×337.5×35mm 600×337.5×35mm 600×337.5×35mm 600×337.5×35mm
Module Size 150×168.75mm 150×168.75mm 150×168.75mm 150×168.75mm
Cabinet Weight 4.6kg 4.6kg 4.6kg 4.6kg
Cabinet Material Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum
Driving Type 1/36 1/36 1/27 1/48
Maintenance Front service Front service Front service Front service
Brightness 0-2000 nits 0-2000 nits 1500 nits 1000 nits
Max/Avg Power 390/136 W/m² 420/147 W/m² 330/100 W/m² 330/100 W/m²
IP Rating Front: IP65
Rear: IP30		 Front: IP65
Rear: IP30		 Front: IP65
Rear: IP30		 Front: IP65
Rear: IP30
Refresh Rate >3840Hz >3840Hz >3840Hz >3840Hz
Installation Type Mounting, Hanging, Stacking Mounting, Hanging, Stacking Mounting, Hanging, Stacking Mounting, Hanging, Stacking
Gray Scale 16bit 16bit 16bit 16bit
Viewing Angle H:170°; V:170° H:170°; V:170° H:170°; V:170° H:170°; V:170°
Operational Temp -20℃~+50℃ -20℃~+50℃ -20℃~+50℃ -20℃~+50℃
Operational Humidity 10%-90%RH 10%-90%RH 10%-90%RH 10%-90%RH
Applications
  • Digital Signage systems
  • Chain stores
  • Street furniture
  • Billboards
  • Football stadiums
  • Perimeter LED posters
  • Arena displays
Technical diagram of P0.7 COB LED Display components and structure P0.7 COB LED Display installation and application examples
Packing and Shipping
Packing: Anti-shaking wooden cabinet / Air flight case / Strong carton
Shipping port: Shenzhen, China
Shipping methods: Air, Express, Ocean, Land Transportation
Delivery time: 10-15 working days after confirming receipt of payment
Frequently Asked Questions
Q1: Can you provide customized services?
A1: Yes, we can design different categories of products according to your demand.
Q2: Is it OK to print our logo on the LED screen product?
A2: Yes, we can print your logo according to your request.
Q3: Can I order a sample for the LED display screen?
A3: Yes, we welcome you to order a sample to test and check quality. You can choose any item that you want.
Q4: How much is the freight?
A4: The shipping cost is determined by the size of the screen and the project information provided in your inquiry.
Q5: Do you offer a guarantee for the products?
A5: Yes, we offer 2 years warranty on our products.
