Outdoor Flexible LED Display with Maximum Bending Degree 75° and IP68 Waterproof Dustproof
Product Details:
| Place of Origin: | China |
| Brand Name: | VW |
| Certification: | CE, ROHS |
| Model Number: | P3.8 P6.67 P8 P10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood case, Carton box |
| Delivery Time: | 15 days |
| Payment Terms: | T/T |
| Supply Ability: | 3000 sqm/month |
|
Detail Information |
|||
| Product Name: | Outdoor Flexible LED Display With Maximum Bending Degree 75° And IP68 Waterproof Dustproof | Pixel Pitch: | 3.81mm / 6.67mm / 8mm / 10mm |
|---|---|---|---|
| LED Type: | SMD | Cabinet DImension: | 640mm * 640mm / 640mm *960mm |
| Module Size: | 320mm * 320mm | Cabinet Weight: | 17KG /25KG |
| Max/Avg Power: | 700/210 W/㎡ | IP Rating: | IP68 |
| Brightness: | 5000 - 6000 Nits | ||
| Highlight: | 75° Flexible LED Display,IP68 Waterproof Flexible LED Display,Outdoor Flexible LED Display |
||
Product Description
Outdoor Flexible LED Display with Maximum Bending Degree 75° and IP68 Waterproof Dustproof
Product Description
The Outdoor Flexible LED Display is engineered for versatile outdoor applications, featuring an impressive 75° maximum bending capability that allows for creative, curved installations. Built with an IP68 rating, this display is fully waterproof and dustproof, making it exceptionally durable and reliable in challenging weather conditions. Perfect for dynamic, high-impact displays, this flexible LED solution ensures vibrant visuals that withstand the elements.
Product Features
- Pixel Pitch Options: Available in 3.81mm, 6.67mm, 8mm, and 10mm for flexible display resolutions.
- LED Type: SMD technology for vibrant and efficient performance.
- Cabinet Dimensions: 640mm × 640mm and 640mm × 960mm options for versatile installation setups.
- Module Size: 320mm × 320mm, providing a modular and scalable design.
- Cabinet Weight: Available in 17kg and 25kg options for lightweight and durable setups.
- Power Consumption: Maximum power of 700 W/㎡ and average power of 210 W/㎡ for energy-efficient operation.
- IP Rating: IP68 waterproof and dustproof for high durability in outdoor environments.
- Brightness: High brightness range of 5000 to 6000 nits, ensuring visibility even in bright sunlight.
Technical Parameters
| Product Model | P3.81 | P6.67 | P8 | P10 |
| Pixel Pitch | 3.81mm | 6.67mm | 8mm | 10mm |
| LED Type | SMD 1921 | SMD3535 | SMD3535 | SMD3535 |
| Cabinet Dimension | 640*640/960 mm | 640*640/960 mm | 640*640/960 mm | 640*640/960 mm |
| Module Size | 320* 320 mm | 320* 320 mm | 320* 320 mm | 320* 320 mm |
| Cabinet Weight | 25/17 KG | 25/17 KG | 25/17 KG | 25/17 KG |
| Cabinet Material | Steel | Steel | Steel | Steel |
| Driving Type | 1/10 | 1/7 | 1/4 | 1/2 |
| Brightness | 5000 - 6000nits | 5000 - 6000nits | 5000 - 6000nits | 5000 - 6000nits |
| Max/Avg Power | 700/210 W/㎡ | 700/210 W/㎡ | 700/210 W/㎡ | 700/210 W/㎡ |
| Environment | Outdoor | Outdoor | Outdoor | Outdoor |
| IP Rating | IP68 | IP68 | IP68 | IP68 |
| Refesh Rate | >3840HZ | >3840HZ | >3840HZ | >3840HZ |
| Installation Type | Mounting/Hanging | Mounting/Hanging | Mounting/Hanging | Mounting/Hanging |
| Gray Sacle | 14Bit | 14Bit | 14Bit | 14Bit |
| Viewing Angle | H:120° V:120° | H:120° V:120° | H:120° V:120° | H:120° V:120° |
| Operation Temp | -20° ~ + 60° | -20° ~ + 60° | -20° ~ + 60° | -20° ~ + 60° |
| Operation Humidity | 10% ~ 90 % RH | 10% ~ 90 % RH | 10% ~ 90 % RH | 10% ~ 90 % RH |
Advantage
Flexible
High Performance
Q&A
FAQ:
Q1: What control system is used, and how does it work?
A1: We use the Nova Taurus Series asynchronous control system, which supports cluster playback and management. You can easily control it via various devices, including APP, smartphone, Wi-Fi, iPad, laptop, PC, or through cloud control. It's very user-friendly and convenient.
Q2: Can I place a sample order for an LED screen?
A2: Yes, we encourage sample orders for testing and quality evaluation. Mixed samples are also accepted.
Q3: Can I have my logo printed on the product?
A3: Absolutely. Please let us know in advance and confirm the design based on our sample before production begins.
Q4: What is your delivery time?
A4: Typically, delivery takes 7-15 days after the deposit is received. However, the exact time depends on the order size and items.
Q5: What is your warranty policy?
A5: We offer a 2-year warranty. We also provide full support for structure design, installation issues, system troubleshooting, and screen usage.
Our professional after-sales team, along with your dedicated sales engineer, will assist with any questions you may have after your order.
