P0.9 Full flip-chip COB Fine Pixel Pitch LED Display with 600x337.5mm Cabinet Size
P0.9 Full flip-chip COB Fine Pixel Pitch LED Display with 600x337.5mm Cabinet Size
Brand Name
Visual World
Product Model
P0.9
Certificate
EMC,CE,FCC,ROHS
Country Of Origin
CN
MOQ
Negotiate
Unit Price
Negotiate
Payment Method
T/T
Supply Capacity
5000 sqm/month
Product Details
Highlight:
600x337.5mm Fine Pixel Pitch LED Display
,P0.9 Fine Pixel Pitch LED Display
Pixel Pitch:
P0.7/P0.9/P1.25/P1.56
Refresh Rate:
＞3840Hz
Brightness:
600-800nits
Durability:
100000 Hours
Cabinet Material:
Die-casting Aliuminum
Display Type:
LED
Size:
600x337.5mm
Maintenance:
Front/Rear Service
LED Type:
Full Flip-chip COB
Product Description
Detailed Specifications And Features
P0.9 Full Flip-Chip COB Fine Pixel Pitch LED Display
Advanced 600x337.5mm cabinet size LED display featuring full flip-chip COB technology for superior performance and reliability.
Product Overview
Full inverted COB process with comprehensive protection technology including anti-knock, waterproof, moisture-resistant, and salt spray protection. This eliminates common LED screen failures in high humidity and high salt spray environments.
Key Features
- Full flip-chip COB process with anti-collision, waterproof, moisture-proof, and salt spray protection
- Ultra-low power consumption - only 33W per cabinet at 600nits brightness
- Ultra-high brightness up to 1200nits with only 52W per cabinet
- Cold screen design with maximum temperature ≤39°C (white screen) and ≤36°C (video playback)
- Low radiation CLASS B design for high-end customer requirements
- Smart module support for real-time monitoring of voltage, temperature, signal, and dead pixel detection
Technical Specifications
| Model | P0.7 | P0.9 | P1.25 | P1.56 |
|---|---|---|---|---|
| Pixel Pitch | 0.7mm | 0.9mm | 1.25mm | 1.56mm |
| LED Type | COB | COB | COB | COB |
| Cabinet Dimension | 600*337.5*35mm | 600*337.5*35mm | 600*337.5*35mm | 600*337.5*35mm |
| Module Size | 150x168.75 mm | 150x168.75 mm | 150x168.75 mm | 150x168.75 mm |
| Cabinet Weight | 4.6kg | 4.6kg | 4.6kg | 4.6kg |
| Cabinet Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Driving Type | 1/36 | 1/36 | 1/27 | 1/48 |
| Maintenance | Front service | Front service | Front service | Front service |
| Brightness | 0-2000 nits | 0-2000 nits | 1500 nits | 1000 nits |
| Max/Avg Power | 390/136 W/m² | 420/147 W/m² | 330/100 W/m² | 330/100 W/m² |
| IP Rating | Front: IP65 / Rear: IP30 | Front: IP65 / Rear: IP30 | Front: IP65 / Rear: IP30 | Front: IP65 / Rear: IP30 |
| Refresh Rate | >3840Hz | >3840Hz | >3840Hz | >3840Hz |
| Installation Type | Mounting Hanging Stacking | Mounting Hanging Stacking | Mounting Hanging Stacking | Mounting Hanging Stacking |
| Gray Scale | 16bit | 16bit | 16bit | 16bit |
| Viewing Angle | H:170°; V:170° | H:170°; V:170° | H:170°; V:170° | H:170°; V:170° |
| Operational Temp | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
| Operational Humidity | 10%-90%RH | 10%-90%RH | 10%-90%RH | 10%-90%RH |
Applications
- Digital Signage Systems
- Chain Stores
- Street Furniture
- Billboards
- Football Stadiums
- Perimeter LED Posters
- Arena Displays
Packaging & Shipping
Our Fine Pixel Pitch LED Display is carefully packaged and shipped to ensure safe delivery:
Packaging
- Protective bubble wrap layer prevents transportation damage
- Sturdy cardboard box with foam padding for additional protection
- Clearly labeled with product name, model number, and shipping information
Shipping
- Multiple shipping methods available for timely and secure delivery
- Domestic orders: FedEx, UPS, and DHL
- International orders: Air or sea freight options
- Comprehensive shipment tracking and monitoring
- Final inspection and testing before customer delivery
Frequently Asked Questions
What's the weight and thickness of the LED cabinet?
The weight of one cabinet is about 4.5kg. The thickness is about 3.5cm.
What pitch do you have for COB Fine Pixel Pitch LED Display?
We have small pitches from P0.7 to P1.56.
How to install?
You only need to stack the cabinets one by one to install the screen on the structure on the wall. The cabinet is lightweight (4.5kg/pcs), making it convenient for workers to assemble.
Are you a trading company or manufacturer?
VISUAL WORLD is a professional LED display manufacturer with 10 years of industry experience, including professional R&D and QC teams.
What is the control system? How is it?
We use Nova Taurus Series asynchronous control system that supports cluster play and management. Compatible with APP/Phone/WIFI/iPad/Laptop/PC/Cloud control for easy and convenient operation.
What is your best service?
One-to-one sales engineer responsibility system including: project consultation and solution development, order tracking and updates, installation and usage guidance, and comprehensive after-sales support.
How about your Warranty Term?
2-year warranty with professional after-sales team and dedicated sales engineer support for any questions or problems.
