5000nits P3.9 Outdoor LED Display 250*500mm with 45° design for Various Splicing

Product Details:

Place of Origin: CN
Brand Name: VW
Certification: CE, ROHS
Model Number: Smart Block Plus

Payment & Shipping Terms:

Minimum Order Quantity: Negotiate
Price: Negotiate
Packaging Details: Plywood box
Delivery Time: 15 days
Payment Terms: T/T
Supply Ability: 1500sqm/month
Get Best Price Contact Now

Detail Information

Refresh Rate: 3840Hz Operating Temperature: -20°C~50°C
Power Consumption: 600W/㎡ Operating Humidity: 10%~90%
Installation Method: Wall Mounted/Hanging Edge: 45° Design
Module Size: 250mm*500mm Brightness: 5000nits
IP Rate: IP67 Material: Aluminum
High Light:

250*500mm Outdoor LED Display

,

P3.9 Outdoor LED Display

,

5000nits Outdoor LED Display

Product Description

5000nits P3.9 Outdoor LED Display 250*500mm with 45° design for Various Splicing



Product Description:

Our SMART BLOCK-PLUS series Outdoor LED Display Module is designed to meet a wide range of outdoor applications. This module is 250mm*500mm in size, integrated technology and high-end products. Our led modules highly integrate the main components of the led display in one panel, making it possible to complete the display in a small size. It enables it to be assembled into a variety of abnormal sizes and can be used as different angle corner display.



Features:

  • Integrated design :Integrate power supply, receiving card and module into one cabinet.
  • Ip67 :High protection level, waterproof and dustproof.
  • Efficient heat dissipation module :No need external air-conditioning.
  • Cable all-in-one design :Signal and power cable all in one.
  • LIGHT WEIGHT : only 3.5kg/pcs, save shipping cost.
  • Magnetic design :Quick disassembly and installation.
  • 45° design :Bevel edge design, various shapes splicing.



Technical Parameters:

Product Model: P2.97 P3.91
Pixel Pitch: 2.97 mm 3.91 mm
LED Type: SMD1415 SMD1921
Cabinet Dimension: 250×500 mm 320×320x37 mm
Module Size: 250x250 mm 250x250 mm
Cabinet Weight: 3.5 kg/pcs 3.5 kg/pcs
Cabinet Material: Die-casting Aluminum Die-casting Aluminum
Driving Type: 1/21 1/16
Brightness: >5000 nits >5000 nits
Max/Avg Power: 97w/pcs 97w/pcs
Maintenance: Front service Front service
Environment: Outdoor Use Outdoor Use
IP Rating: F: IP66, R: IP66 F: IP66, R: IP66
Refresh Rate: >3840 Hz >3840 Hz
Installation Type: Mounting/Hanging Mounting/Hanging
Gray Scale: 14 bit 14 bit
Viewing Angle: H:140°;V:140° H:140°;V:140°
Operational Temp: -20℃~+60℃ -20℃~+60℃
Operational Humidity: 10%~90% RH 10%~90% RH



Applications:

Looking for a led module for individual outdoor use? Our SMART BLOCK PLUS integrated led module is the highly recommended to your outdoor video wall projects. Special 45° edges design allows this panel to build led screen with different shape or display area. If you want to learn more about this product, please feel free to contact!

5000nits P3.9 Outdoor LED Display 250*500mm with 45° design for  Various Splicing 0



Our Service:

Pre-sale service:

Inquiries will be replied within 24 hours. Market research and forecast for customer. Provide unique and professional solutions based on customer's requirement. Data sheet and samples offered. Other required services such as special packing design, factory visiting and so on.



In-sale service:

Tracking producing procedures all the time. Provide photos and videos as per customer's requirement during production. Free spare parts provided.



After-sale service:

Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours. Warranty: 24 months. Free technician training. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.

5000nits P3.9 Outdoor LED Display 250*500mm with 45° design for  Various Splicing 1



FAQ:

Q1:What technical supports can you offer?
A1:We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory.


Q2:How long is the warranty?
A2:The standard warranty is 2 year.


Q3:Do you provide any free spare parts in each order?
A3:Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED lamp, IC, mask, power supply, receiving card, etc.
