상세 정보 |
|||
| 제품 이름: | P8 실외 고정 LED 디스플레이 알루미늄 프로필 28kg/공원 입구 용 캐비닛 | 픽셀 피치: | P8 |
|---|---|---|---|
| 모듈 크기: | 480*320mm | 캐비닛 치수: | 960x960x77mm |
| 캐비닛 무게: | 28kg | 유지: | 전면/후면 서비스 |
| IP 등급: | IP65 | 명도: | > 6500nits |
| 강조하다: | outdoor fixed LED display aluminum profile,P8 LED display for park entrance,28kg cabinet LED display screen |
||
제품 설명
The P8 outdoor fixed LED display meets TUV 5VB fireproof certification and features dual protection through its aluminum chassis and IP65 multi-layer waterproof construction. Its all-aluminum dense heat sink and partial voltage power supply enable low-temperature operation and extended lifespan. The hard-wired design ensures physical stability, while the slim 77mm profile and 32kg/m² weight simplify wall mounting and front/back maintenance. The module's left/right interchangeability significantly reduces operational and maintenance costs.
- Waterproof: Durable, waterproof, fast heat dissipation aluminum cabinet with IP65 protection level for outdoor use.
- Front & Rear service: Can be installed against the wall, with full front and rear maintenance design, convenient installation and saving installation space.
- High brightness: Customized module PCB and designated power supply make it up to 600nits brightness.
- Wide viewing angles: Wide viewing angles horizontal 140°, vertical 140° allows audience to watch the screen clearly from distances.
- Quick installation: Simple internal cables connection and positioning pins, quick and easy installation.
| Item | P5.7 | P6.67 | P8 | P10 |
|---|---|---|---|---|
| Pixel Pitch | 5.7mm | 6.67mm | 8mm | 10mm |
| Module Size | 480*320mm | |||
| Cabinet Size | 960*960*77mm | |||
| Working Voltage | 3.2/4.2V | |||
| Scan Mode | 1/7 | 1/6 | 1/4 | 1/2 |
| Cabinet Material | Aluminum Profile | |||
| Cabinet Weight | 28kg/cabinet | |||
| Brightness | >6500nits | |||
| Power Consumption | 650/228w/m2 | 540/2189w/m2 | 650/228w/m2 | 650/228w/m2 |
| Maintenance | Front/Rear Service | |||
| IP Rating | IP65 | |||
| Refresh Rate | ≥3840Hz | |||
| Viewing Angle | H:140°; V:140° | |||
| Operational Temp | ﹣20~50℃ | |||
| Operational Humidity | 10%~90%RH | |||
- Outdoor creative modeling
- Building entrance
- Park entrance
- Swimming pool
- Advertising billboard
- Playing field
- Outdoor activity area
- Roadside poster
- Building exterior wall
A1: 100% factory. We have more than 10 years of manufacturing experience. OEM & ODM order is warmly welcomed.
A2: Stable and reliable quality, efficient and professional customer service, competitive factory price, fast delivery time.
A3: 7-15 days according to order quantity and season.
A4: Our products have Patent no, CE and ROHS certification, please contact us if you need other certifications.
A5: Low MOQ, 1 square meter or a module checking is available.
A6: A two-year warranty for all products.
A7: You should provide width/height of the display, the main use, the viewing distance, the scene photos, special requirements, then I can provide you with a detailed list of quotations.
